Yamaha VK540EC (VK540 III) 8AC6 1999 BRAKE Diagram

#

Description
Price

1

DISC, BRAKE (RIGHT)

83R-25831-00-00

$186.34

2

CALIPER BODY COMP.1

87R-25730-01-00

$241.25

3

SCREW, ADJUSTING 1

86M-25738-00-00

$8.91

4

LEVER, BRAKE

87R-25726-01-00

$78.68

5

SHIM, CALIPER

86M-25827-00-00

$2.37

6

LOCK, ONE WAY 2

86M-25773-00-00

$8.91

7

RATCHET, ADJUSTING

86M-25771-00-00

$6.58

8

COVER

86M-25772-00-00

$35.52

9

BOLT, CALIPER

86M-25818-00-00

$4.29

10

BRACKET, CALIPER

87R-25721-00-00

$30.91

11

BOLT 3

86M-25826-00-00

$1.95

12

SPRING, RETURN

87R-25743-00-00

$7.74

13

BRACKET, ADJUSTING

87R-25722-00-00

$45.48

14

PLATE, BACK UP

86M-25733-00-00

$12.78

15

BOLT, FITTING

86M-25833-00-00

$0.28

16

PIN 2

86M-25744-00-00

$1.27

17

BOLT, FLANGE(8AB)

95817-10050-00

$5.03

18

PAD, CALIPER 2

89J-25811-00-00

$23.38

19

PAD, CALIPER 2

89J-25911-00-00

$50.02
