Yamaha VK1NFPMV (VK PROFESSIONAL II EPS) 8LP71 2021 SEAT Diagram

#

Description
Price

1

EMBLEM

8FN-24897-00-00

$9.29

2

ASSIST, GRIP

8FN-2474A-00-00

Unavailable

3

ASSIST,GRIP 2

8FN-2474W-00-00

Unavailable

4

ASSIST GRIP WARMER ASSY 1

8GS-2474B-00-00

$144.59

5

COVER 1

8GJ-2842M-00-00

$17.70

6

RIVET, BLIND(8CR)

90267-47186-00

$2.16

7

BOLT, FLANGE

90105-10151-00

Unavailable

8

BRACKET, ASSIST GRIP 1

8FN-2474H-00-00

Unavailable

9

STOPPER

8FA-27114-00-00

$3.61

10

PROTECTOR,1

8FN-2476U-00-00

Unavailable

11

BOLT, FLANGE

95822-08014-00

$6.58

12

SINGLE SEAT ASSY

8KW-24710-01-00

Unavailable

13

SEAT COVER COMP.

8KW-2470F-01-00

$304.86

14

CLAMP, ROD

89A-77159-00-00

$9.61

15

TANDEM SEAT ASSY

8KW-24750-01-00

Unavailable

16

SEAT COVER COMP. ,2

8KW-2470H-01-00

Unavailable

17

SEAT BACK ASSY

8FN-24790-21-00

Unavailable

18

NUT, FLANGE

95702-06500-00

Unavailable

19

BOLT, FLANGE

90105-10151-00

Unavailable
