Yamaha VK10YS (RS VIKING PROFESSIONAL) 8GS50 2009 TRACK DRIVE 3 Diagram

#

Description
Price

1

KNOB, SHIFTER

8GS-18164-00-00

$137.98

2

BEARING(3DL)

93306-20226-00

$33.15

3

CIRCLIP(47Y)

99009-35500-00

$6.17

4

NUT, U FLANGE

95607-12200-00

$5.43

5

GUIDE, PLATE STOPPER

8GS-18161-01-00

$69.78

6

BOLT, FLANGE(JN5)

95817-08016-00

$4.12

7

WASHER (856)

90201-12317-00

$4.15

8

SHIFT GUIDE COMP.

8GS-18104-01-00

$269.06

9

BUSH, BIMETAL FORMED

90384-19001-00

$4.57

10

LEVER, SHIFT 4

8GS-18152-01-00

$59.63

11

SPRING, COMPRESSION (8FA1)

90501-130A0-00

$2.20

12

COLLAR (8FA1)

90387-06059-00

$26.74

13

PIN (8FA1)

90249-06002-00

$12.22

14

CIRCLIP (J10)

93410-06053-00

$5.62

15

WASHER, PLATE (214-27417-00)

90201-06042-00

$6.58

16

NUT,SELF-LOCKING

95607-06200-00

$10.25

17

KNOB, SHIFT LEVER

8GS-18174-00-00

$39.54

18

SCREW, COUNTERSUNK

90151-05048-00

$5.62

19

BRACKET

8GS-18128-01-00

$19.71

20

BOLT, FLANGE

95817-08014-00

$1.94

21

WASHER, PLATE

90201-08060-00

$7.35

22

BOLT, FLANGE(8AB)

95817-08020-00

$7.00

23

GUIDE

8GS-18179-01-00

$25.55

24

BOLT, FLANGE

95817-06012-00

$1.49
