Polaris VICTORY VEGAS ALL OPTIONS - V04GB16/NC16 WHEELS, REAR (SPOKED) - V04GB16/CA/CB/CC/CE/CG/CJ/CK/CL/DA/DB/DC/DE/DG/DJ/DK/DL/LA/LB/LC/LE/LG/LJ/LK/LL/UA/UB/UC/UE/UG/UJ/UK/UL/UA/UE (4989548954B04) Diagram

#

Description
Price

1

Shaft, Spindle, Wheel, Rear

1013926

Unavailable

2

SCREW

7518178

$7.14

2

SCREW

7518178

$7.14

3

Mount, Axle Adjustment

5133481

$27.94

3

Mount, Axle Adjustment

5133481

$27.94

4

Spacer, RH

5631480

$5.79

5

SPACER, BEARING, LH

5631479

$3.97

6

Screw

7518044

$6.19

7

WASHER, FLAT

7556234

$3.17

8

Asm., Sprocket, 64T

1341448

Unavailable

9

Nipple, Spoke

5132870

Unavailable

9

Rim

5133677

Unavailable

9

Flap, Rim

5812233

$13.10

9

Spoke, Outer

5334021

Unavailable

9

Spoke, Inner

5334023

Unavailable

9

Asm., Wheel [Incl. 10-14]

1520615

$713.99

10

SEAL

3610094

$31.75

10

SEAL

3610094

$31.75

11

BEARING, BALL

3514405

$19.84

11

BEARING, BALL

3514405

$19.84

12

Spacer, Bearing

5334138

$61.89

13

Ring, Retaining

7710526

$10.32

14

Weight, Balance

1520618

Unavailable

15

Rotor, Brake

1910623

$349.99

16

Screw

7518297

$5.56

17

Tire, Rear

5412373

$319.99

18

Tube, Tire, Inner

1821398

$46.84

19

Nut, Hex

7547266

$23.81

20

Washer, Indicator, Axle

5245087-236

$15.70
