Polaris VICTORY VEGAS ALL OPTIONS - V04GB16/NC16 BRAKES, REAR - V04GB16/NC16/ALL OPTIONS (4989548954B13) Diagram

#

Description
Price

1

Kit, Bleeder Screw, Boot

2201173

$12.99

1

Kit, Boots, Caliper, Rear

2201174

Unavailable

1

Kit, Pin, Retainer, Spring, Clip

2201175

$21.81

1

Asm., Caliper, Rear

1910619

Unavailable

1

Kit, Brake Pad

2202491

Unavailable

2

Asm., Brake Hose, Rear [Footpeg]

1910746

Unavailable

2

Asm., Brake, Rear/FWDCTR [Floorboard]

1910794

Unavailable

3

SCREW

7517704

$7.19

3

SCREW

7517704

$7.19

4

CLAMP-REAR BRAKE

7080983

$3.99

5

Dart

5433140

Unavailable

6

SCREW

7517405

$10.39

7

WSHR-6.4X18.0X1.6 ZPB

7556064

$5.22

8

Reservoir

1930882

Unavailable

9

Clamp, Hose

7080904

Unavailable

9

Clamp, Hose

7080904

Unavailable

10

Hose, Reservoir [Footpeg]

1910656

Unavailable

10

Hose, Reservoir [Floorboard]

1910796

$45.24

11

CABLE-TIE,DIA12-50MM,WTHR-RES.

7080138

$2.41

12

Bolt

1930848

Unavailable

12

Bolt

1930848

Unavailable

13

Washer, Banjo, Copper

7556028

$1.59

13

Washer, Banjo, Copper

7556028

$1.59

14

Screw [Footpeg]

7518141

$4.79

14

Screw [Floorboard]

7517391

$8.79

15

Cylinder, Master, Rear [Footpeg]

1910620

$141.65

15

Cylinder, Master, Rear [Floorboard]

1910762

Unavailable

16

SPRING-EXTENSION,BRAKE, RETURN [Floorboard]

7042288

Unavailable

16

Spring, Ext., Brake Return [Footpeg]

7042186

Unavailable

17

PEDAL, BRAKE LEVER [See R.H. Footpeg/Floorboard/Brake Pg. A7, Ref. 5]

-------

Unavailable

18

Clip, Wiring Harness

7080930

$2.22

19

SWITCH, PRESSURE

4010372

Unavailable
