Honda VFR800AAC (04) INTERCEPTOR ABS, JPN, VIN# JH2RC464-4M600001 REAR BRAKE HOSE (ABS) Diagram

#

Description
Price

1

RUBBER, MUFFLER MOUNTING

18421-MB0-000

$6.34

2

MAIN HOSE, RR. BRAKE

43311-MCW-D11

$77.79

3

SUB-HOSE, RR. BRAKE

43312-MCW-D11

$77.79

4

PLATE, BRAKE HOSE

43313-MBG-000

$7.39

5

HOSE, RR. ABS UNIT JOINT

43313-MCW-D11

$41.92

6

HOSE, RR. PCV DIRECT

43314-MCW-D11

$36.20

7

CLAMP, RR. BRAKE HOSE

43320-MCW-D10

$4.77

8

SCREW, BLEEDER

43352-MG9-006

$5.44

9

CAP, BLEEDER This part replaces 43353-MG9-006.

43353-461-771

$5.05

9

CAP, BLEEDER This part replaces 43353-443-761.

43353-461-771

$5.05

9

CAP, BLEEDER

43353-461-771

$5.05

10

VALVE ASSY., PROPORTIONING This part replaces 46200-MCW-D11.

46200-MCW-D12

$381.31

10

VALVE ASSY., PROPORTIONING

46200-MCW-D12

$381.31

11

CLAMP, BRAKE HOSE

52115-MAT-000

$6.28

12

MODULATOR ASSY., ABS

57100-MCW-D11

$1,515.66

13

COLLAR, ABS MODULATOR STAY

57106-MCW-D10

Unavailable

14

STAY, PCV

57120-MCW-D10

$45.77

15

STAY, RR. ABS MODULATOR

57135-MCW-D10

$33.67

16

SCREW, PAN (5X8)

90115-KV3-700

$2.61

17

SCREW, PAN (6X14)

90118-MR1-000

$3.10

18

BOLT B, OIL (10X22)

90145-MBG-003

$13.08

19

BOLT, OIL (10X22) (SAGA)

90145-MS9-612

$7.54

20

WASHER, OIL BOLT

90545-300-000

$3.99

21

O-RING (5.8X1.9) (NISSIN)

91355-MG9-006

$3.15

22

BOLT, FLANGE (6X12)

95701-06012-07

$1.62

23

BOLT, FLANGE (6X32) (Honda Code 2105856)

95701-06032-00

$1.89

24

BOLT, SOCKET (8X18)

96600-08018-00

$1.49

25

BOLT, SOCKET (8X45)

96700-08045-00

$1.51
