Honda VFR750RA (90) RC30, JPN, VIN# JH2RC300-LM200001 STAND Diagram

#

Description
Price

1

SHIM K, DIFFERENTIAL CASE (1.00) | (Optional).

41641-HC5-000

$12.43

2

BAR ASSY., SIDE STAND (NOT AVAILABLE)

50540-MR7-000

Unavailable

3

SPRING, SIDE STAND

50541-KE8-000

$3.80

4

TUBE, SIDE STAND SPRING

50544-MR7-000

Unavailable

5

RUBBER, STAND

50548-356-700

$10.50

6

COLLAR, STAND RUBBER SETTING

50549-356-700

$2.70

7

BRACKET, SIDE STAND

50550-MR7-000

Unavailable

8

CAP, CROSSMEMBER SIDE | (Optional).

52161-051-000

$2.33

9

STAND ASSY., MAINTENANCE (NOT AVAILABLE) | (Optional).

85000-MR7-602

Unavailable

10

CAUTION, STAND | (Optional).

85001-MR7-601

Unavailable

11

COLLAR | (Optional).

85020-MR7-010

Unavailable

12

SHAFT, MAINTENANCE STAND | (Optional).

85031-MR7-000

Unavailable

13

BUSH, CLAMP | (Optional).

85032-MR7-000

Unavailable

14

NUT, MAINTENANCE STAND | (Optional).

85033-MR7-000

Unavailable

15

BOLT, SIDE STAND PIVOT

90108-ML7-610

Unavailable

16

BOLT, FLANGE (8X25) This part replaces 90135-MR7-000.

90103-MZ5-000

$4.75

17

NUT, SIDE STAND

90203-MF9-710

$3.67

18

WASHER, THRUST (24X13)

90501-MF9-710

Unavailable

19

WASHER, THRUST (24X10)

90502-MF9-710

Unavailable

20

BEARING, BALL (6906ZZ) | (Optional).

91005-MR7-003

Unavailable

21

WASHER, PLAIN (18MM) | (Optional).

94101-18700

Unavailable

22

PIN, SPRING (4X30) | (Optional).

94305-40301

Unavailable

23

CIRCLIP, OUTER (19MM) | (Optional).

94510-19000

$1.49

24

BOLT, FLANGE (6X25) This part replaces 96000-06025-07.

96001-06025-07

$1.49

24

BOLT, FLANGE (6X25)

96001-06025-07

$1.49
