Honda VFR750FA (86) 750 INTERCEPTOR, JPN, VIN# JH2RC240-GM000008 MAIN STAND + SIDE STAND Diagram

#

Description
Price

NI

BULK HOSE, VINYL (17.5X20.5X1000) (17.5X20.5X50)

95003-55001-10M

Unavailable

1

STAND, MAIN (NOT AVAILABLE)

50500-ML7-600

Unavailable

2

SPRING ASSY., MAIN STAND

50525-ML7-000

Unavailable

3

PIPE, MAIN STAND PIVOT

50526-MB6-000

Unavailable

3

PIPE, MAIN STAND PIVOT This part replaces 50526-ML7-000.

50526-MB6-000

Unavailable

4

WASHER, STOPPER This part replaces 50527-ML7-000.

50527-ML7-700

Unavailable

4

WASHER, STOPPER

50527-ML7-700

Unavailable

5

BRACKET, SIDE STAND (NOT AVAILABLE) | Use up to Frame SN GM000381 This part replaces 50535-ML7-000.

50535-ML7-010

Unavailable

5

BRACKET, SIDE STAND (NOT AVAILABLE)

50535-ML7-010

Unavailable

6

STAY, COWL (LOWER)

50536-ML7-000

Unavailable

7

HOOK, MAIN STAND SPRING

50538-ML7-000

$7.90

8

CAP, SIDE STAND BRACKET (NOT AVAILABLE)

50539-ML7-000

Unavailable

9

BAR ASSY., SIDE STAND This part replaces 50540-ML7-000.

50540-ML7-700

Unavailable

9

BAR ASSY., SIDE STAND

50540-ML7-700

Unavailable

10

SPRING, SIDE STAND

50541-ML7-000

Unavailable

11

RUBBER, STAND

50548-356-700

$10.50

12

COLLAR, STAND RUBBER SETTING

50549-356-700

$2.70

13

SCREW, SIDE STAND PIVOT

90108-KG0-000

$7.96

13

SCREW, SIDE STAND PIVOT This part replaces 90108-ML7-000.

90108-KG0-000

$7.96

14

NUT, U (10MM)

90304-GE8-003

$3.67

15

WASHER (20MM) This part replaces 90501-ML7-000.

90501-ZV5-A10

$3.00

15

WASHER (20MM)

90501-ZV5-A10

$3.00

16

PIN, SPLIT (2.5X30) This part replaces 94201-25250.

94201-25300

$1.49

16

PIN, COTTER (2.5MM)

94201-25300

$1.49

16

BOLT, FLANGE (6X10) | Use up to Frame SN GM000381 This part replaces 95700-06010-07.

95701-06010-07

$1.62

16

BOLT, FLANGE (6X10) | Use up to Frame SN GM000381

95701-06010-07

$1.62

17

BOLT, FLANGE (6X10) | Use up to Frame SN GM000381

95701-06010-07

$1.62

17

BOLT, FLANGE (6X10) | Use from Frame SN GM000382 This part replaces 96000-06010-07.

96001-06010-07

$1.62

17

BOLT, FLANGE (6X10) | Use from Frame SN GM000382

96001-06010-07

$1.62

18

BOLT, FLANGE (8X28) This part replaces 95700-08028-07.

95701-08028-07

$1.49

18

BOLT, FLANGE (8X28)

95701-08028-07

$1.49

19

BOLT, FLANGE (6X25) This part replaces 96000-06025-07.

96001-06025-07

$1.49

19

BOLT, FLANGE (6X25)

96001-06025-07

$1.49
