Honda VF750FA (84) 750 INTERCEPTOR, JPN, VIN# JH2RC150-EM100006 TO JH2RC150-EM103270 FRONT SHOCK ABSORBER Diagram

#

Description
Price

1

FORK ASSY., R. FR. This part replaces 51400-MB2-671.

51400-MB2-672

Unavailable

1

FORK ASSY., R. FR.

51400-MB2-672

Unavailable

2

SPRING, FR. FORK (NOT AVAILABLE)

51401-MB2-671

Unavailable

3

COLLAR, SPRING

51402-MB2-671

Unavailable

4

VALVE, OIL LOCK

51403-MB2-003

Unavailable

5

PLATE, SPRING JOINT

51403-ME5-003

Unavailable

6

SPRING, OIL LOCK VALVE (NOT AVAILABLE)

51404-MA6-003

Unavailable

7

SEAT, SPRING (NOT AVAILABLE)

51405-MA6-003

Unavailable

8

RING, STOPPER

51405-MC7-003

$2.39

9

RING, STOPPER (NOT AVAILABLE)

51406-MB1-771

Unavailable

10

PIPE, R. FR. FORK

51410-MB2-671

Unavailable

11

SPRING, REBOUND

51411-ME5-003

Unavailable

12

RING, BACK-UP

51412-463-003

$7.75

12

RING, BACK-UP This part replaces 51412-463-305.

51412-463-003

$7.75

13

BUSH, FORK PIPE

51414-463-003

$15.77

14

BUSH, SLIDER

51415-MB9-781

$20.08

15

SLEEVE, FORK PIPE

51415-463-003

$18.74

16

GASKET This part replaces 51417-ME1-671.

51417-MJ0-013

Unavailable

16

GASKET

51417-MJ0-013

Unavailable

17

SPRING, PISTON (NOT AVAILABLE)

51418-ME1-671

Unavailable

18

CASE, R. (LOWER) This part replaces 51421-MB2-003.

51421-MB2-013

Unavailable

19

COLLAR, PISTON (NOT AVAILABLE)

51423-MB1-771

Unavailable

20

PIECE, OIL LOCK (NOT AVAILABLE)

51432-MB2-003

Unavailable

21

PIECE, OIL LOCK

51432-MB7-611

Unavailable

22

ROD, ADJUSTER (NOT AVAILABLE)

51433-MB1-771

Unavailable

23

SPRING, CLICK (NOT AVAILABLE)

51434-MC7-003

Unavailable

24

WASHER, SPECIAL (5MM)

51435-MC7-003

$2.92

25

PISTON (NOT AVAILABLE)

51436-MB1-771

Unavailable

26

RING, PISTON

51437-ME5-003

Unavailable

27

HOLDER, GREASE (NOT AVAILABLE)

51438-MB9-781

Unavailable

28

WASHER, HOLDER (NOT AVAILABLE)

51439-MB9-781

Unavailable

29

PIPE, SEAT

51440-MB2-003

Unavailable

30

RUBBER, STOPPER

51441-MC7-003

Unavailable

31

BOOT, PISTON CASE

51442-MC7-003

$10.65

32

WASHER, L. SIDE (NOT AVAILABLE)

51444-MB1-771

Unavailable

33

HOLDER, BOOT

51445-MC7-003

$6.48

34

CIRCLIP (INNER)

51447-463-003

$4.53

35

PIN, PARALLEL (NOT AVAILABLE)

51448-MB1-771

Unavailable

36

BOLT ASSY., FR. FORK

51450-ME5-003

Unavailable

37

BOLT ASSY., FR. FORK

51454-MB2-671

Unavailable

38

CAP, AIR VALVE

51456-MB2-003

Unavailable

39

CAP, ADJUSTING PLATE

51458-MG5-611

Unavailable

40

SEAL SET, FR. FORK This part replaces 51490-MB9-781.

51490-MB9-782

$38.57

40

SEAL SET, FR. FORK

51490-MB9-782

$38.57

40

SEAL SET, FR. FORK This part replaces 51490-MG2-305.

51490-MB9-782

$38.57

40

SEAL SET, FR. FORK This part replaces 51490-463-305.

51490-MB9-782

$38.57

41

MARK, FR. FORK

51496-MC7-670

$4.99

42

FORK ASSY., L. FR.

51500-MB2-672

Unavailable

43

PIPE, L. FR. FORK (NOT AVAILABLE)

51510-MB2-671

Unavailable

44

CASE, L. (LOWER) This part replaces 51521-MB2-003.

51521-MB2-013

Unavailable

44

CASE, L. (LOWER)

51521-MB2-013

Unavailable

45

CASE, L. PISTON

51530-ME7-671

Unavailable

46

BUSH, PIVOT

51532-MB2-300

Unavailable

47

PIPE, SEAT

51540-MB2-003

Unavailable

48

HOLDER 1B, FR. FORK AXLE (NOT AVAILABLE) This part replaces 51634-410-003.

95014-41100

Unavailable

49

SLEEVE (NOT AVAILABLE)

53134-MG5-671

Unavailable

50

BOLT, HEX. (NOT AVAILABLE)

53135-MG5-671

Unavailable

51

EQUALIZER, FR. SHOCK

53137-MB2-003

Unavailable

52

JOINT, L. AIR

53139-MG5-671

Unavailable

53

STABILIZER, FR. FORK

53240-MB2-000

Unavailable

54

BOLT, SOCKET (6X18) This part replaces 90116-MC7-003.

96700-06018-17

Unavailable

54

BOLT, SOCKET (6X18) This part replaces 90118-MC7-003.

96700-06018-17

Unavailable

54

BOLT, SOCKET (6X18)

96700-06018-17

Unavailable

55

BOLT, SOCKET (8MM) (SHOWA) This part replaces 90116-283-010.

90116-383-721

$5.13

55

BOLT, SOCKET (8X27)

90116-383-721

$5.13

56

BOLT, HEX. (6X17) (NOT AVAILABLE)

90125-MB2-003

Unavailable

57

BOLT, SOCKET (8X17) This part replaces 90153-MB0-000.

90153-MB0-405

$3.38

57

BOLT, SOCKET (8X17)

90153-MB0-405

$3.38

58

GASKET, FR. FORK DRAIN VALVE

90543-273-000

$2.46

59

WASHER, SPECIAL (8MM)

90544-283-000

$2.87

60

RING, STOPPER

90602-MG5-670

Unavailable

61

DUST SEAL

91254-463-003

$22.51

62

O-RING (35.5X2)

91302-MA3-661

$2.65

63

O-RING (13.8X2.4) (NOK) This part replaces 91308-MC7-003.

91311-PH7-003

$2.28

63

O-RING (13.8X2.4) (NOK)

91311-PH7-003

$2.28

64

O-RING (6.8X1.9)

91306-PJ4-000

$3.01

64

O-RING (6.8X1.9) This part replaces 91310-MC7-003.

91306-PJ4-000

$3.01

65

O-RING (38.5X2)

91351-GR1-000

$2.92

65

O-RING (38.5X2) This part replaces 91352-MG5-671.

91351-GR1-000

$2.92

66

O-RING

91353-MG5-671

Unavailable

67

O-RING (29.2X3.5)

91356-MA3-661

$3.69

68

O-RING (49.4X3.1)

91308-MJ0-003

$3.58

68

O-RING (49.4X3.1) This part replaces 91399-MB0-003.

91308-MJ0-003

$3.58

69

CAP, SOCKET BOLT (8MM) This part replaces 91455-MB0-000.

91455-MB0-010

$3.77

69

CAP, SOCKET BOLT (8MM)

91455-MB0-010

$3.77

70

BOLT, HEX. (6X8) This part replaces 92000-06008-0A.

92101-06008-0A

$1.49

70

BOLT, HEX. (6X8)

92101-06008-0A

$1.49

71

BOLT, STUD (8X50) This part replaces 92700-08050-3B.

92900-08028-3B

$1.59

71

BOLT, STUD (8X50)

92900-08028-3B

$1.59

72

SCREW, PAN (5X10)

93500-05010-0A

$1.49

72

SCREW, PAN (5X10) This part replaces 93500-05010-1A.

93500-05010-0A

$1.49

72

SCREW, PAN (5X10) This part replaces 93510-05010-0A.

93500-05010-0A

$1.49

73

NUT, HEX. (8MM)

94030-08000

$1.49

74

WASHER, PLAIN (8MM)

94101-08000

$1.49

75

WASHER, SPRING (8MM)

94111-08000

$1.49

76

BALL, STEEL (#5) (5/32)

96211-05000

$1.49
