Honda VF1100SA (84) V65 SABRE, USA, VIN# 1HFSC170-EM000001 TO 1HFSC170-EM010029 REAR BRAKE PANEL Diagram

#

Description
Price

1

HOSE, RR. BRAKE (NOT AVAILABLE)

43310-MB3-003

Unavailable

2

MASTER CYLINDER ASSY., RR. BRAKE (NOT AVAILABLE)

43500-MB3-671

Unavailable

3

CONNECTOR, MASTER CYLINDER

43503-MB2-006

$12.02

4

BOOT

43504-MB2-006

$10.04

5

CUP, MASTER CYLINDER OIL (NOT AVAILABLE)

43511-443-761

Unavailable

6

HOSE, MASTER CYLINDER (NOT AVAILABLE)

43512-MB3-000

Unavailable

7

CAP, OIL CUP

43510-MB4-671

Unavailable

8

CLAMP, MASTER CYLINDER OIL HOSE

43514-445-771

$12.27

9

PISTON SET, MASTER CYLINDER (NISSIN) This part replaces 43520-MB2-305.

43520-MB2-315

$46.51

9

PISTON SET, MASTER CYLINDER (NISSIN)

43520-MB2-315

$46.51

10

ROD, PUSH

43530-MB2-006

$34.74

11

STOPPER, HOSE END (NOT AVAILABLE)

43535-MB3-000

Unavailable

12

DIAPHRAGM

45520-300-000

$9.05

13

PLATE, DIAPHRAGM

45521-MJ6-006

$4.06

13

PLATE, DIAPHRAGM This part replaces 45521-300-010.

45521-MJ6-006

$4.06

14

CIRCLIP

46182-500-013

$4.90

15

PIN, BRAKE ROD

46503-371-000

Unavailable

16

JOINT, BRAKE ROD

46504-MB2-006

Unavailable

17

BOLT, OIL (10X22) (SAGA) This part replaces 90145-KE8-000.

90145-KM3-751

$11.02

17

BOLT, OIL (10X22)

90145-VM0-000

Unavailable

17

BOLT, OIL (10X22) (SAGA) This part replaces 90145-KM3-750.

90145-KM3-751

$11.02

17

BOLT, OIL (10X22) (SAGA)

90145-KM3-751

$11.02

17

BOLT, OIL (10X22) (SAGA) This part replaces 90145-961-010.

90145-KM3-751

$11.02

18

WASHER (7X12)

90501-310-000

$1.74

19

WASHER, OIL BOLT

90545-300-000

$3.99

20

O-RING (14.8X2.4)

91212-422-006

$2.56

21

SCREW-WASHER (4X12)

93893-04012-08

$1.49

21

SCREW-WASHER (4X12) This part replaces 93893-04012-18.

93893-04012-08

$1.49

22

NUT, HEX. (8MM)

94002-08000-0S

$1.49

23

PIN, COTTER (1.6X25) This part replaces 94201-16150.

94201-16250

$1.49

23

PIN, COTTER (1.6X25)

94201-16250

$1.49

24

BOLT, FLANGE (6X12) This part replaces 95700-06012-00.

95701-06012-00

$1.62

24

BOLT, FLANGE (6X12)

95701-06012-00

$1.62

25

BOLT, FLANGE (6X18) BOLT, HEX. (6X18) This part replaces 95700-06018-00.

95701-06018-00

$1.62

25

BOLT, FLANGE (6X18)

95701-06018-00

$1.62
