Sea-doo Utopia 205, Edition 1, 2006 Engine Compartment And Accessories Diagram

#

Description
Price

1

Engine Access Cover | Includes 1 to 19

204072308

Unavailable

2

Seal Tray 1000Mm Long

219704368

$13.99

3

HANDLE, WHITE - Call your local BRP dealership

291000608

Unavailable

4

Hex. Flange Screw K40 X 16

241141660

$1.48

5

Flat Washer 4 mm, Stainless

234042600

$1.15

6

Hex. Screw M6 X 50

207065060

$2.22

7

Flat Washer M6, Stainless

234062600

$0.77

8

Hex. Elastic Stop Nut M6

232561600

$1.15

9

ACCESS COVER PLUG - Call your local BRP dealership

204072432

Unavailable

10

POLE CLIP - Call your local BRP dealership | Challenger S

204070342

Unavailable

11

PHILLIPS SCREW M4.2 X 25 - Call your local BRP dealership

209642560

Unavailable

12

HINGE - Call your local BRP dealership

204072386

Unavailable

13

OVAL HEAD PHILLIPS COUNTERSUNK SCREW M6 - Call your local BRP dealership

208563060

Unavailable

14

Loctite 243, 10 ml

293800060

$21.49

15

Access Cover Strap

204072369

Unavailable

16

SOCKET SCREW M6 X 25 - Call your local BRP dealership

205462560

Unavailable

17

Hex. Elastic Stop Nut M6

232561600

$1.15

18

Flat Washer M6, Stainless

234062600

$0.77

19

Not Available As Spare Part - Friction Washer

Unavailable

20

DOUBLE LATCH STUD - Call your local BRP dealership

204130052

Unavailable

21

Loctite 243, 10 ml

293800060

$21.49

22

TIE RAP WITH DART - Call your local BRP dealership

204130098

Unavailable

23

DART, BLACK - Call your local BRP dealership

204130099

Unavailable

24

Tie Wrap 368 mm

293750008

$1.04

25

Engine Cover

204072384

Unavailable

26

Seal Tray 1000Mm Long

219704368

$13.99

27

Was 293200017 Neoprene Seal

219704365

$149.99

28

GROMMET - Call your local BRP dealership

293720017

Unavailable

29

Shock Bracket

204073074

$27.99

30

HEX. SCREW M5 X 16 - Call your local BRP dealership

207151660

Unavailable

31

Loctite 243, 10 ml

293800060

$21.49

32

Latch Ass'y

269700109

$24.99

33

Latch Ass'y

269700109

$24.99

34

Latch Ass'y

269700109

$24.99

35

Latch Spring

269700017

$9.19

36

SHIM - Call your local BRP dealership

269700015

Unavailable

37

Hex. Screw M6 X 50

207065060

$2.22

38

Stainless Flat Washer M6

234061600

$0.33

39

Loctite 243, 10 ml

293800060

$21.49

40

LATCH PROTECTOR - Call your local BRP dealership

204070952

Unavailable

41

Pole Support

291000642

Unavailable

42

PHILLIPS SCREW M4 X 25 - Call your local BRP dealership

208642560

Unavailable

43

Flat Washer 4 mm

234040600

$0.55

44

Loctite 243, 10 ml

293800060

$21.49

45

Strap Tie

204070234

Unavailable

46

PHILLIPS SCREW M4 X 20 - Call your local BRP dealership

208442060

Unavailable

47

HINGE ASS'Y - Call your local BRP dealership | Includes 19 to 21

204070127

Unavailable

48

HINGE ROD - Call your local BRP dealership

204070204

Unavailable

49

Cotter Pin M2.5 X 12

204070205

Unavailable

50

Hex. Screw M6 X 25

207162560

$1.47

51

Stainless Flat Washer M6

234061600

$0.33

52

Loctite 243, 10 ml

293800060

$21.49

53

Gas Shock

204071925

Unavailable

54

Shock Bracket

204071673

Unavailable

55

HEX. SCREW M5 X 25 - Call your local BRP dealership

207152560

Unavailable

56

Loctite 243, 10 ml

293800060

$21.49

57

Inlet Vent, Port Side

204072315

Unavailable

57

Inlet Vent, Starboard

204072316

Unavailable

58

RIVET_POP 1/8 X ,750 - Call your local BRP dealership

293150036

Unavailable

59

Vent Cover Ass'y, Port Side | Includes 50 to 51

204072317

Unavailable

59

VENT COVER ASS'Y, STARBOARD - Call your local BRP dealership | Includes 50 to 51

204072318

Unavailable

60

FLAT WASHER - Call your local BRP dealership

211200019

Unavailable

61

PHILLIPS SCREW 1 - Call your local BRP dealership

204100154

Unavailable

62

Lock Washer 1/4”

211200025

$1.29

63

HEX. NUT 1/4 - Call your local BRP dealership

211100026

Unavailable

64

Loctite 243, 10 ml

293800060

$21.49

65

Seat Storage, Starboard

204072299

Unavailable

65

Seat Storage, Port Side

204072419

Unavailable

66

SLOTTED BOLT 1/4?-20 X 1? - Call your local BRP dealership

204100095

Unavailable

67

Vent Cover Ass'y, Port Side

204072102

Unavailable

68

Vent Cover Ass'y, Starboard

204072104

Unavailable

69

PHILLIPS TAPPING SCREW #8 X 1 - Call your local BRP dealership

204100049

Unavailable

70

FINITION WASHER - Call your local BRP dealership

204100057

Unavailable

71

Was 293200017 Neoprene Seal

219704365

$149.99

72

Flat Washer 10 mm, Stainless

234002600

$2.22

73

HEX. NUT 3/8-16 - Call your local BRP dealership

211100063

Unavailable

74

Loctite 271, 10 ml

293800005

$26.99

75

Helicoidal Lock Washer M10 | XT Models

234101601

$1.15

76

GRAB HANDLE - Call your local BRP dealership

204071122

Unavailable

77

Threaded Stud

204100031

Unavailable

78

Loctite 271, 10 ml

293800005

$26.99

79

Was 293800041 Loctite Primer 7649

219704458

$39.99
