Yamaha TZ250N (TZ250) 5KE2 2001 TRANSMISSION Diagram

#

Description
Price

1

AXLE, MAIN (14T)

5KE-17411-10-00

Unavailable

1

AXLE, MAIN (18T)

5KE-17411-20-00

Unavailable

2

BEARING

93306-20526-00

Unavailable

3

BEARING(3XV)

93306-00442-00

$41.99

4

PLATE, BEARING COVER

5KE-15381-00-00

Unavailable

5

SCREW, COUNTERSUNK (4H7)

90151-06014-00

Unavailable

6

GEAR, 2ND PINION

4DP-17121-12-00

Unavailable

7

GEAR, 3RD/4TH PINION (23T/25T)

5KE-17131-00-00

Unavailable

7

GEAR, 3RD/4TH PINION (21T/25T)

5KE-17131-10-00

Unavailable

8

GEAR, 5THPINION (27T)

5F7-17151-01-00

Unavailable

9

GEAR, 6TH PINION

5KE-17161-01-00

Unavailable

9

GEAR, 6TH PINION

5KE-17161-11-00

Unavailable

10

WASHER, PLATE(59W)

90201-253K0-00

$8.49

10

WASHER, PLATE (5F7)

90201-256E6-00

$5.60

11

WASHER, PLATE (5F7)

90201-256E4-00

$12.49

12

CIRCLIP (4L0)

93440-25084-00

Unavailable

13

WASHER PLATE 328171160000

90201-20276-00

Unavailable

14

WASHER PLATE 328171160000

90201-20276-00

Unavailable

14

WASHER, PLATE (5F7)

90201-206E5-00

Unavailable

15

CIRCLIP(1AR)

99009-20400-00

Unavailable

16

AXLE, DRIVE

5KE-17421-00-00

Unavailable

17

GEAR, 1ST WHEEL (28T)

5KE-17211-10-00

Unavailable

17

GEAR, 1ST WHEEL (34T)

5KE-17211-20-00

Unavailable

18

BRG,CYL-CAL ROLLER 7G NT

93310-22057-00

Unavailable

19

GEAR, 2ND WHEEL

4DP-17221-12-00

Unavailable

20

GEAR, 3RD WHEEL (29T)

5KE-17231-00-00

Unavailable

20

GEAR, 3RD WHEEL

5KE-17231-10-00

Unavailable

21

GEAR, 4TH WHEEL (27T)

5KE-17241-00-00

Unavailable

22

GEAR, 5TH. WHEEL (26T)

3YL-17251-00-00

Unavailable

23

GEAR, 6TH WHEEL

5KE-17261-01-00

Unavailable

23

GEAR, 6TH WHEEL

5KE-17261-11-00

Unavailable

24

WASHER, GEAR HOLD 3

5F7-17136-00-00

Unavailable

24

WASHER 434172160000

90209-22082-00

Unavailable

25

BEARING(43G)

93306-20562-00

Unavailable

26

BEARING(3LD)

93306-20464-00

Unavailable

27

PLATE, BEARING COVER

4JT-15381-01-00

Unavailable

28

SCREW, COUNTERSUNK (4H7)

90151-06014-00

Unavailable

29

OIL SEAL (697)

93102-32M07-00

Unavailable

30

PLATE, COVER

3AK-17471-00-00

Unavailable

31

BOLT, SOCKET

91317-05012-00

Unavailable

32

COLLAR

90387-25001-00

Unavailable

33

SPROCKET, DRIVE (14T)(3LC)

93834-14178-00

Unavailable

33

SPROCKET, DRIVE (15T)

93834-15079-00

Unavailable

33

SPROCKET, DRIVE (16T)

93834-16104-00

Unavailable

34

WASHER, LOCK (23X)

90215-21239-00

Unavailable

35

NUT (2K7)

90179-20255-00

Unavailable
