Yamaha TZ250N (TZ250) 5KE2 2001 STEERING HANDLE CABLE Diagram

#

Description
Price

1

HANDLEBAR (LEFT)

3YL-26121-00-00

Unavailable

2

HANDLEBAR (RIGHT)

3YL-26122-01-00

Unavailable

3

END, GRIP

4JT-26246-00-00

$17.49

4

BOLT,SOCKET

91317-06025-00

$5.60

5

GRIP (L.H)

47X-26241-00-00

Unavailable

6

GRIP (R.H)

47X-26242-00-00

Unavailable

7

TUBE, THROTTLE GUIDE

3YL-26243-00-00

Unavailable

8

RING, LEAF

3Y1-26249-00-00

$9.99

9

CAP, GRIP UPPER

3YL-26281-01-00

Unavailable

10

CAP, GRIP LOWER

3YL-26282-00-00

Unavailable

11

BOLT, SOCKET

91317-05020-00

$3.28

12

CABLE, THROTTLE 1

5KE-26311-00-00

Unavailable

13

CABLE, THROTTLE 2

5KE-26312-00-00

Unavailable

14

BOLT 177262530100

90123-06007-00

$21.99

15

CABLE, CLUTCH

5KE-26335-00-00

Unavailable

16

CLAMP

90464-16115-00

Unavailable

17

SPRING, LOCK

5F6-26368-00-00

Unavailable

18

GASKET, EXHAUST

98507-05008-00

Unavailable

19

WASHER(3SX)

92907-05100-00

Unavailable
