Yamaha TZ250M (TZ250) 5KE1 2000 CRANKSHAFT PISTON Diagram

#

Description
Price

1

CRANKSHAFT ASSY

5KE-11400-00-00

Unavailable

2

BEARING

93306-30571-00

$72.99

3

. BEARING

93306-30632-00

Unavailable

4

BEARING

93306-30571-00

$72.99

5

WASHER(4DP)

90209-24327-00

$44.99

6

WASHER(3XV)

90209-24316-00

Unavailable

7

BEARING

93310-52403-00

$129.99

8

ROD, CONNECTING

5KE-11651-01-00

Unavailable

9

OIL SEAL(3YL)

93101-44160-00

Unavailable

10

KEY, WOODRUFF(3MA)

90280-04051-00

Unavailable

11

OIL SEAL(3MA)

93102-25438-00

$22.99

12

OIL SEAL

93102-35030-00

Unavailable

13

CIRCLIP

278-17424-01-00

$21.99

14

PISTON (STD)

5KE-11631-10-A0

Unavailable

14

PISTON (STD)

5KE-11631-10-B0

$252.99

14

PISTON (STD)

5KE-11631-10-C0

Unavailable

15

RING, PISTON

4JT-11611-11-00

Unavailable

16

PIN, PISTON

4XM-11633-01-00

Unavailable

17

BEARING, CYLINDRICAL(4XM)

93310-315S4-00

Unavailable

18

CIRCLIP (4G0)

93450-16068-00

Unavailable

19

GEAR, DRIVE

5KE-11536-00-00

Unavailable

20

GEAR, PRIMARY DRIVE

5KE-16111-00-00

Unavailable

21

WASHER, PLATE

90201-10144-00

Unavailable

22

BOLT, WASHER BASED(1TX)

90105-10445-00

Unavailable
