Yamaha TY250C (TY250) 1976 BRAKE PEDAL Diagram

#

Description
Price

1

PEDAL, BRAKE

434-27211-01-93

Unavailable

2

SPRING, TORSION

(90508-14269-00)

Unavailable

3

PEDAL, BRAKE

(493-27242-02-93)

Unavailable

4

PIN, CLEVIS

90240-06043-00

Unavailable

5

PIN, COTTER

91490-20025-00

$1.99

6

WASHER, PLATE (371)

90201-06431-00

$5.60

7

SHAFT, BRAKE PEDAL

(434-27212-01-00)

Unavailable

8

BOLT, HEXAGON

97017-06020-00

$4.06

9

SCREW, CYLINDER.HEAD

(92301-06020-00)

Unavailable

10

SPRING, COMPRESSION

(90501-10186-00)

Unavailable

11

O-RING (648)

93210-14167-00

$9.49

12

SPRING, TORSION

(90508-35145-00)

Unavailable

13

WASHER, PLAIN (434)

90201-14411-00

$8.49

14

. CIRCLIP

99001-12600-00

Unavailable

15

CABLE, BRAKE

434-26351-00-00

Unavailable

16

PIN, WITH HOLE (248-27228-00)

90240-06006-00

Unavailable

17

YBS66-6 WASHER, PLAIN

92990-06200-00

Unavailable

18

PIN, COTTER

91490-25020-00

Unavailable

19

SPRING, COMPRESSION (294-27236-00)

90501-09054-00

Unavailable

20

PIN 1562723700

90249-12008-00

Unavailable

21

NUT, SPEC''L SHAPE

90179-06006-00

Unavailable

22

CLIP (156-83525-00)

90468-10050-00

Unavailable

23

PEDAL, BRAKE

(493-27211-10-00)

Unavailable
