Description

Price

1

FENDER, FRONT

3AW-21511-20-00

$83.99

2

BRACKET, FENDER

2JX-21512-00-00

$67.99

3

SCREW, C.R. BINDING (2T4)

90154-05004-00

$4.72

4

NUT, S/L FLANGE

95607-05200-00

$9.49

5

GUIDE, WIRE

1A8-21518-00-00

$7.99

6

BOLT,SOCKET

91317-06020-00

Unavailable

7

FENDER, REAR

3AW-21611-20-00

$149.99

8

DAMPER, SIDE COVER (437)

90480-12053-00

$7.49

9

BOLT, WITH WASHER (10V)

90119-06063-00

$9.49

10

BRACKET, LICENSE

2JX-21685-01-00

$62.99

11

BOLT, WITH WASHER

90119-06152-00

$7.49

12

BRACKET, REFLECTOR

2JX-21641-00-00

Unavailable

13

SCREW, PAN

98517-05012-00

$4.73

14

WASHER(1RW)

92907-05600-00

$3.78

15

PLUG

90338-07018-00

$7.49

16

SEAL

2JX-21669-00-00

Unavailable

17

FLAP

34X-21691-00-00

Unavailable

18

COVER, REAR FENDER

2JX-21651-00-00

Unavailable

19

SCREW, BINDING

98907-06014-00

Unavailable

20

COLLAR (8G8)

90387-06681-00

Unavailable

21

EMBLEM, YAMAHA

99247-00080-00

Unavailable

Yamaha TW200MC (TRAILWAY CA) 5FY6 2000 FENDER Diagram

FENDER, FRONT

BRACKET, FENDER

SCREW, C.R. BINDING (2T4)

NUT, S/L FLANGE

GUIDE, WIRE

BOLT,SOCKET

FENDER, REAR

DAMPER, SIDE COVER (437)

BOLT, WITH WASHER (10V)

BRACKET, LICENSE

BOLT, WITH WASHER

BRACKET, REFLECTOR

SCREW, PAN

WASHER(1RW)

PLUG

SEAL

FLAP

COVER, REAR FENDER

SCREW, BINDING

COLLAR (8G8)

EMBLEM, YAMAHA
