Yamaha TTR250VC (TT-R250 CA) 5GFP 2006 OIL PUMP Diagram

#

Description
Price

1

OIL PUMP ASSY

4GY-13300-01-00

Unavailable

2

GEAR, PUMP DRIVEN 2

4GY-13326-00-00

Unavailable

3

CIRCLIP(24H)

99009-11400-00

$8.49

4

GASKET, PUMP COVER

4GY-13329-00-00

$6.99

5

SCREW, PAN

98507-06035-00

$8.49

6

GASKET (3Y1)

90430-06156-00

$4.29

7

STRAINER, OIL

22F-13411-01-00

$29.99

8

ELEMENT ASSY, OIL CLEANER

1UY-13440-02-00

$16.49

9

O-RING (341)

93210-54175-00

$13.49

10

O-RING (583 OIL DRAIN BOLT)

93210-07135-00

$6.99

11

COVER, OIL ELEMENT

4GY-13447-00-00

Unavailable

12

BOLT (583 OIL DRAIN)

90109-06419-00

$8.49

13

BOLT, SOCKET

91317-06070-00

$4.99

14

BOLT,SOCKET

91317-06020-00

Unavailable

15

GASKET 256113960000

90430-06014-00

Unavailable

16

SCREW

90153-06029-00

Unavailable

17

BOLT, WASHER BASED(4GY)

90105-122A1-00

Unavailable

18

GASKET(3FD)

90430-12213-00

Unavailable

19

PIPE, DELIVERY 1

4GY-13161-00-00

Unavailable

20

BOLT, UNION(3GM)

90401-10159-00

Unavailable

21

GASKET (5R6)

90430-10171-00

Unavailable

22

BOLT, UNION(3AJ)

90401-08133-00

Unavailable

23

GASKET

90430-08119-00

Unavailable

24

RELIEF VALVE ASSY

4GY-13490-00-00

Unavailable

25

O-RING (611)

93210-10096-00

Unavailable

26

STAY

4GY-13151-00-00

Unavailable

27

BOLT, FLANGE(4MY)

95027-06012-00

Unavailable
