Yamaha TTR250VC (TT-R250 CA) 5GFP 2006 INTAKE Diagram
#
Description
Price
2
O-RING(36Y)
93210-40659-00
Unavailable
3
BOLT,SOCKET
91317-06020-00
Unavailable
5
AIR CLEANER CASE ASSY
4GY-14401-01-00
Unavailable
10
HOLDER, GUIDE
4GY-14459-00-00
Unavailable
11
SEAL
1LN-14462-00-00
Unavailable
15
DUCT
4GY-14437-00-00
Unavailable
16
PIPE, DRAIN
3AJ-1443E-00-00
Unavailable
17
CLIP (806-24358-00)
90467-15012-00
Unavailable
18
HEAD
4GY-28386-00-00
Unavailable
19
WASHER, SPECIAL 1
2TK-21757-00-00
Unavailable
20
SCREW, C.R. BINDING (2T4)
90154-05004-00
Unavailable
21
CHAMBER, AIR 2
4GY-13591-00-00
Unavailable
22
BREATHER ASSY
4GY-15370-00-00
Unavailable
23
STAY
4GY-14413-00-00
Unavailable
24
SCREW, WITH WASHER (5U8)
90159-06056-00
Unavailable
25
PIPE, BREATHER 2
4GY-11167-00-00
Unavailable
26
CLIP(1JH)
90467-11106-00
Unavailable
27
CLIP (4X4)
90467-12052-00
Unavailable
28
PIPE, DRAIN
4GY-1443E-00-00
Unavailable
29
HOSE CLAMP ASSY
90450-58002-00
Unavailable
30
BOLT, WITH WASHER (30X)
90119-06096-00
Unavailable
31
BOLT, WITH WASHER(2WG)
90119-06172-00
Unavailable
32
GROMMET(80K)
90480-13428-00
Unavailable
33
COLLAR (3L6)
90387-06737-00
Unavailable
34
PIPE, JOINT
4GY-14485-00-00
Unavailable
