Suzuki TS185 (1976) SEAT Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE | K; TO 45100-28830-403 This part replaces 45100-28000-403.

45100-28831-865

Unavailable

1

SEAT | L,M; TO 45100-28402-403 This part replaces 45100-28401-403.

45100-28402-865

Unavailable

1

SEAT | A; FROM 45100-28402-403

45100-28402-865

Unavailable

2

PIN

09200-06018

$2.06

3

.COTTER PIN This part replaces 04111-20156.

04111-2015A

$1.49

4

BOSS, SEAT CLAMP

45210-26001

Unavailable

5

CLAMP, SEAT

45211-26001

Unavailable

6

SPRING

09448-17007

Unavailable

7

BOLT | K,L,M This part replaces 01122-08458.

01500-08453

$2.50

7

BOLT | A This part replaces 01122-08408.

01500-0840A

$2.60

8

.LOCK WASHER This part replaces 08321-21088.

08321-01087

$2.13

9

NUT This part replaces 08312-11088.

08310-00087

$2.13

10

CUSHION

09321-08006

$2.90

11

CUSHION

09321-10002

$2.22

12

CARRIER, SPORTS | K,L,M; OPT TO 46310-28401

46310-28400

Unavailable

12

CARRIER, SPOTS | A; OPT

46310-28401

Unavailable
