Suzuki TS125 (1981) FRONT WHEEL Diagram

#

Description
Price

1

HUB, WHEEL

54110-29300

Unavailable

2

HUB FLANGE, FRONT RH

54112-30500

Unavailable

3

SCREW This part replaces 02122-06168.

02122-06167

$1.49

4

RETAINER, HUB BEARING RH

54151-30500

$8.42

5

BOLT, CANISTER This part replaces 01107-06168.

01500-06167

$1.97

6

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13

7

NO DESCRIPTION AVAILABLE This part replaces 54210-48500.

54210-48502

Unavailable

8

SHOE SET, BRAKE This part replaces 54410-07002.

54401-07810

Unavailable

9

SPRING This part replaces 09443-07001.

09443-07025

$2.08

10

NO DESCRIPTION AVAILABLE This part replaces 54441-48500.

54441-48502

Unavailable

11

O RING (D:2.5,ID:13.8) This part replaces 09280-14003.

09280-14011

$4.77

12

WASHER This part replaces 09160-14001.

09160-14055

$2.39

13

NO DESCRIPTION AVAILABLE This part replaces 54451-32400.

54451-32401

Unavailable

14

BOLT This part replaces 01107-06258.

01500-06257

$1.97

15

GEAR, SPEEDOMETER (NT:27) This part replaces 54611-28401.

54611-28402

Unavailable

16

PINION, SPEEDOMETER (NT:9) This part replaces 54621-28400.

54621-28401

Unavailable

17

BUSH

54632-01001

$12.80

18

WASHER,5.1X9X0. This part replaces 09160-05001.

09160-05001-A05

$1.87

19

DRIVER

54661-29300

$4.52

20

THRUST WASHER (18.5X24X1)

09160-18002

$2.38

21

CIRCLIP

08331-11189

Unavailable

22

SCREW,3X4.3 This part replaces 09134-03101.

09134-03101-A05

$1.78

23

OIL SEAL This part replaces 09285-43001.

09283-43004

$14.03

24

AXLE, FRONT This part replaces 54711-16503.

54711-16504

Unavailable

25

SPACER (12.5X19X52) This part replaces 09180-12041.

09180-12144

$10.30

26

SPACER

54741-41100

$15.13

27

WASHER This part replaces 08322-11128.

08322-01127

$1.84

28

NUT This part replaces 08314-31128.

08314-3112A

$2.41

29

PIN This part replaces 04111-30308.

04111-3030A

$1.49

30

BEARING This part replaces 08143-62017.

08143-6201B

$10.80

31

BEARING This part replaces 08123-62017.

08133-62017

$18.47

32

TIRE, FRONT (2.75-21) | IRC

55100-48500

Unavailable

33

TIRE, FRONT | IRC This part replaces 55200-16510.

55200-16511

$36.73

34

PROTECTOR, INNER TUBE | IRC This part replaces 55261-16510.

55261-14540

$3.83

35

RIM, WHEEL (1.60x21)

55311-48020

$171.00

36

SPOKE SET

55320-29300

$64.68
