Honda TRX500FEA (06) FOURTRAX FOREMAN 4X4 ES, USA, VIN# 1HFTE317-64100001 REAR WHEEL Diagram

#

Description

Price

1

HUB, R. RR. This part replaces 42610-HP0-A00.

42610-HN0-670

$137.89

2

HUB, L. RR. This part replaces 42620-HP0-A00.

42620-HR0-F00

$72.22

3

WHEEL SUB-ASSY., RR. (SILVER) This part replaces 42650-HP0-A00.

42650-HP0-A50

$123.30

3

WHEEL SUB-ASSY., RR. (SILVER)

42650-HP0-A50

$123.30

4

TIRE (25X10-12) (DUNLOP) This part replaces 42711-HN2-A21.

42711-HP0-A01

Unavailable

4

TIRE (25X10-12) (DUNLOP)

42711-HP0-A01

Unavailable

4

TIRE (25X10-12) (MAXXIS) This part replaces 42711-HR0-F01.

42711-HR4-AJ1

$98.36

5

VALVE, RIM (TR412)

42753-HF1-670

$5.37

6

CAP, WHEEL CENTER

44732-HC4-010

$23.29

7

NUT, AXLE (20MM)

90304-HM7-A10

$12.05

8

NUT, WHEEL

90314-HM5-A10

$3.39

9

DUST SEAL (21.4X28.2X5) (ARAI)

91255-HM7-003

$7.63

10

RING, SIDE SEAL

91265-HA8-003

$27.70

11

PIN, SPLIT (4.0X40)

94201-40400

$1.49
