Description

Price

1

MAINSHAFT (13T)

23210-HP1-600

$152.59

2

COUNTERSHAFT

23220-HP1-600

$145.93

3

COLLAR, COUNTERSHAFT

23225-HP1-670

$16.14

4

GEAR, COUNTERSHAFT LOW (29T)

23411-HP1-600

$103.16

5

COLLAR, COUNTERSHAFT LOW GEAR (19X22X10.1)

23412-HP1-670

$10.62

6

GEAR, MAINSHAFT SECOND (14T)

23421-HP1-600

$50.21

7

GEAR, COUNTERSHAFT SECOND (25T)

23431-HP1-600

$97.26

8

COLLAR, COUNTERSHAFT SECOND (27X30X10)

23432-HP1-670

$11.26

9

GEAR, MAINSHAFT THIRD (16T)

23441-HP1-600

$100.93

10

GEAR, COUNTERSHAFT THIRD (23T)

23451-HP1-600

$92.40

11

GEAR, MAINSHAFT FOURTH (22T)

23461-HP1-600

$94.66

12

COLLAR, MAINSHAFT FOURTH GEAR SPLINE

23462-HP1-600

$12.62

13

GEAR, COUNTERSHAFT FOURTH (26T)

23471-HP1-600

$105.65

14

GEAR, MAINSHAFT FIFTH (27T)

23481-HP1-600

$97.26

15

COLLAR (25X28X9.7)

23482-HP1-670

$10.62

16

GEAR, COUNTERSHAFT FIFTH (26T)

23491-HP1-600

$110.34

17

SPROCKET, DRIVE (13T)

23802-MEN-730

$39.50

18

BOLT, FLANGE (6X14) (NSHF)

90004-GHB-620

$3.42

19

BOLT, UBS (8X33)

90112-413-000

$3.85

20

WASHER (25X32X1.0)

90401-HP1-670

$2.87

21

PLATE, BEARING HOLDER

90441-KA4-700

$3.35

22

WASHER, SPECIAL (24MM)

90445-HP1-670

$3.45

23

WASHER, THRUST (27.2X35)

90446-ML3-870

$4.85

24

WASHER, THRUST (17.2MM)

90446-357-000

$3.60

25

WASHER, SPLINE (25X31X1.0)

90451-HP1-670

$2.70

26

WASHER, SPECIAL (17MM)

90451-KAE-010

$4.72

27

COLLAR, DRIVE SPROCKET

23802-KSC-670

$14.68

28

WASHER, THRUST (19MM)

90554-KA5-680

$4.37

29

CIRCLIP (OUTER) (25MM)

90602-259-010

$6.16

30

BEARING, RADIAL BALL (25X56X15)

91003-HP1-601

$38.56

31

BEARING, RADIAL BALL

91003-KJ1-003

$23.06

31

BEARING, RADIAL BALL This part replaces 91003-KR1-766.

91003-KJ1-003

$23.06

32

BEARING, SPECIAL RADIAL BALL (6203) (KOYO)

91022-KV3-003

$14.12

33

BEARING, RADIAL BALL (24X56X22.1)

91006-HP1-671

$47.57

34

PLATE, COUNTERSHAFT BEARING

91012-HP1-670

$2.93

35

D-RING (23.75MM) (ARAI)

91201-ML3-873

$3.67

36

OIL SEAL (31X40X7) (ARAI)

91207-ML3-871

$10.65

37

SCREW, SPECIAL FLAT (6X12)

90003-KRN-670

$2.03

38

WASHER, SPLINE (25MM)

90461-MY9-920

$2.43

39

WASHER, LOCK (25MM)

90462-MY9-920
