Description

Price

1

CLIP, OIL DRAIN TUBE

15707-634-000

$5.13

2

PETCOCK ASSY.

16950-HN1-003

$92.08

3

SCREEN SET, FUEL STRAINER

16952-HN1-003

$20.09

4

TUBE, FUEL

16956-HN1-A40

$11.47

5

LEVER, PETCOCK

16963-HN1-000

$3.28

6

O-RING (11.8X3.55)

16997-467-000

$2.11

7

TANK, FUEL

17510-HN1-000

Unavailable

8

PROTECTOR, TANK HEAT (LOWER)

17515-HN1-A40

$69.45

9

RUBBER, HEAT PROTECTOR

17518-HN1-000

$23.82

10

COLLAR, FR. SEAT

17518-KZ4-710

$5.80

11

TUBE, FUEL CAP BREATHER

17521-HN1-000

$6.96

12

SEAL A, HEAT PROTECTOR

17525-HN1-300

Unavailable

13

CAP ASSY., FUEL TANK

17620-HN1-000

$32.66

14

GASKET, FUEL CAP This part replaces 17624-KT1-780.

17624-KT1-781

$4.81

15

COLLAR, FUEL TANK SETTING

17626-467-000

$4.76

16

RUBBER, MUFFLER

18334-KA3-830

$3.89

17

COLLAR, RADIATOR MOUNTING

19052-MGH-640

$2.48

17

COLLAR, RADIATOR MOUNTING This part replaces 19052-MN8-000.

19052-MGH-640

$2.48

18

RUBBER, STOPPER

50352-KE1-000

$4.28

19

BOLT, SPECIAL (6X32)

90101-HM8-000

$4.39

20

SCREW-WASHER (5X35)

90102-HN1-A40

$1.97

21

BOLT, FLANGE (6MM)

90111-187-000

$5.59

22

SCREW, SPECIAL (5MM)

91422-MT8-770

$2.90

23

CLIP, WASHER MOUTH

91504-SD5-901
