Honda TRX300EXA (94) FOURTRAX 300EX, JPN, VIN# JH2TE190-RT100001 FRONT BRAKE CALIPER Diagram

#

Description
Price

1

PAD SET, RR. (NISSIN) This part replaces 06435-HA5-670.

06435-HA5-671

$42.81

1

PAD SET, RR. (NISSIN)

06435-HA5-671

$42.81

2

SEAL SET, PISTON

06451-961-405

$6.56

3

SCREW, BLEEDER (NISSIN)

43352-568-003

$7.95

4

CAP, BLEEDER

43353-461-771

$5.05

5

CALIPER ASSY., L. FR. (NOT AVAILABLE)

45100-HM3-006

Unavailable

7

PISTON (NISSIN)

45107-HC0-681

$74.26

8

SPRING, PAD

45108-166-006

$7.46

9

BRACKET, L.

45110-GC4-601

Unavailable

10

BRACKET, FR. (A)

45110-HC0-006

Unavailable

11

INDICATOR, L.

45113-HC0-006

$3.39

12

SHIM

45114-GE3-601

$5.92

13

PIN, SLIDE

45115-GE3-602

$11.52

14

SHIM

45116-GE3-601

$5.92

15

BOLT, PIN

45131-166-016

$7.63

16

BOOT, PIN BUSH (NISSIN)

45132-166-016

$5.46

17

BOOT, PIN

45133-166-016

$3.85

18

PLUG, DUST

45134-GE3-601

$4.48

20

CALIPER ASSY., R. FR. (NOT AVAILABLE)

45200-HM3-006

Unavailable

22

PLUG, PIN

45203-MG3-016

$5.12

23

INDICATOR, R.

45213-HC0-006

$3.54

24

PIN, HANGER

45215-GE2-016

$11.52

25

WASHER, WAVE

45216-166-006

$2.34

26

WASHER, CONICAL SPRING

45218-166-006

$3.78

28

BOLT, FLANGE (8X20)

90115-HA7-670

$4.24
