Description

Price

1

SWITCH ASSY., FR. STOP (COO)

35340-HR0-305

$15.99

1

SWITCH ASSY., FR. STOP (COO) This part replaces 35340-ML4-005.

35340-HR0-305

$15.99

2

HOSE COMP A, FR. BRK

45126-HM8-B22

$24.54

3

HOSE COMP B, FR. BRK

45127-HM8-B22

$55.78

4

PIPE, FR. BRAKE

45128-HM8-B20

$15.13

5

BOOT

45504-410-003

$11.17

6

MASTER CYLINDER SUB-ASSY., FR.

45510-HM8-B41

$52.87

7

CAP, MASTER CYLINDER

45513-HA2-006

$25.29

8

HOLDER, MASTER CYLINDER

45517-166-006

$12.44

9

DIAPHRAGM

45520-MG7-006

$9.73

10

PLATE, DIAPHRAGM

45521-HA2-006

$9.96

11

MASTER CYLINDER SET

45530-471-831

Unavailable

12

WASHER, R. OIL BOLT

45535-HC4-840

$8.65

13

WASHER, L. OIL BOLT

45545-HC4-840

$8.65

14

SEPARATOR

46666-HB9-006

$8.64

15

CLAMP, R. BRAKE HOSE

51201-HM8-000

$2.18

16

CLAMP, L. BRAKE HOSE

51202-HM8-000

$2.18

17

CLAMP A, FR. BRAKE HOSE

51207-HM8-000

$8.78

18

CLAMP B, FR. BRAKE HOSE (RR.)

51208-HM8-000

$2.06

19

LEVER, R. HANDLEBAR

53175-HC4-010

$21.00

20

COVER, R. HANDLE

53176-HM8-B00

$2.91

21

BOLT, FLANGE (6X10)

90107-HC5-000

$2.15

22

BOLT, HANDLE LEVER

90114-HM8-B41

$4.00

23

BOLT, FLANGE (8X12)

90115-HM4-930

$3.69

24

BOLT, OIL (10X22) (SAGA)

90145-MS9-612

$6.99

25

WASHER, OIL BOLT

90545-300-000

$6.56

26

CIRCLIP

90651-MA5-671

$2.38

27

SCREW, FLAT (4X12)

93600-04012-0G

$0.84

27

SCREW, FLAT (4X12) This part replaces 93600-04012-1G.
