Description

Price

1

COVER, FR. CRANKCASE

11330-HM8-A50

$182.51

2

COVER, REDUCTION GEAR

11335-HM8-A50

$46.75

3

O-RING, REDUCTION GEAR COVER

11337-HM8-A50

$4.89

4

PROTECTOR, ANGLE SENSOR

11339-HM8-A50

$25.99

5

GASKET, FR. CRANKCASE COVER

11394-HM8-000

$23.38

6

VALVE, RELIEF

15231-HM3-670

$11.32

7

SPRING, RELIEF VALVE

15232-HM3-670

$1.77

8

CAP, RELIEF VALVE

15235-HM3-670

$19.75

9

DIPSTICK, OIL

15651-HM8-000

$9.65

10

PLATE, CLUTCH CAM

22820-HN6-000

$15.00

11

SPRING, CAM PLATE SIDE

22825-HN0-671

$3.37

12

PLATE, CLUTCH LIFTER

22830-HB6-000

$19.01

13

SUB-LEVER, CLUTCH LIFTER

22840-HM8-000

$32.10

14

BOLT, CLUTCH ADJUSTING

22846-HB3-000

$5.64

15

RETAINER, BALL

22860-HB3-000

$7.28

16

GEAR, REDUCTION (41T/10T)

24615-HN0-771

$14.49

17

GEAR, REDUCTION (40T/12T)

24616-HN0-771

$15.94

18

GEAR, REDUCTION (7/43T)

24617-HN0-771

$7.34

19

MOTOR ASSY., CONTROL

31300-HM8-A51

$205.85

20

PLATE, WIRE GUIDE

31305-HM8-A50

$1.87

21

SENSOR ASSY., ANGLE This part replaces 38800-HP0-A11.

38800-HR3-A21

$23.60

21

SENSOR ASSY., ANGLE

38800-HR3-A21

$23.60

22

BOLT, SOCKET (5X20)

90116-HP5-600

$2.88

23

WASHER (8MM)

90485-040-000

$1.61

24

BEARING, RADIAL BALL (15X32X9)

91009-HF1-671

$20.12

25

BEARING, NEEDLE (10X14X10) (TORRINGTON)

91021-HN0-671

$12.28

26

BEARING, RADIAL BALL (696ZZ)

91050-HN0-A11

$9.54

27

BEARING, RADIAL BALL (626ZZ)

91060-HN0-A11

$9.79

28

BEARING, RADIAL BALL (698ZZ)

91070-HN0-A11

$10.02

29

OIL SEAL (10X20X5) (ARAI) This part replaces 91201-KM1-005.

91202-HC0-003

$3.30

29

OIL SEAL (10X20X5) (ARAI)

91202-HC0-003

$3.30

30

O-RING (8X1.7) (ARAI)

91306-HB3-003

$1.72

31

O-RING (18X3) (ARAI)

91307-KF0-003

$2.67

32

O-RING (16.8X1.9)

91308-HM8-A51

$2.46

33

O-RING, CONTROL MOTOR

91351-HM8-A51

$3.55

34

NUT, HEX. (8MM)

94030-08000

$0.97

35

WASHER, PLAIN (5MM)

94101-05800

$0.90

36

PIN, DOWEL (8X10)

94301-08100

$2.04

37

PIN, DOWEL (8X14)

94301-08140
