Description

Price

1

PETCOCK ASSY.

16950-HM8-003

$97.35

2

SCREEN SET, FUEL STRAINER

16952-HM8-003

$23.67

3

LEVER, PETCOCK NH1 (BLACK)

16963-HM8-000ZA

$10.46

4

O-RING (11.8X3.55)

16997-467-000

$2.11

5

RUBBER, TANK MOUNTING

17508-KN5-670

$2.59

5

RUBBER, TANK MOUNTING This part replaces 17508-MN1-670.

17508-KN5-670

$2.59

6

TANK, FUEL

17510-HM8-B60

$195.44

7

PROTECTOR, TANK HEAT (LOWER)

17515-HM8-B40

$105.71

8

TUBE, FUEL CAP BREATHER

17521-HA2-670

$6.99

9

CAP ASSY., FUEL TANK

17620-HF7-000

$55.16

10

GASKET, FUEL CAP

17624-HF7-000

$7.81

11

COLLAR, FUEL TANK SETTING

17626-467-000

$4.76

12

TUBE, FUEL

17681-HN6-A50

$11.26

13

RUBBER, ENGINE HEAD MOUNTING

50201-HM8-003

$19.11

14

PLATE, CROSS

50300-HN6-000

$18.33

15

COLLAR, SEAT MOUNTING

77207-464-000

$7.63

16

BOLT, SPECIAL (6X32)

90101-HM8-000

$4.39

17

SCREW-WASHER (5X80)

90101-HN7-000

$4.04

18

CLIP, SPLASH GUARD

90653-HC4-900

$1.49

20

RUBBER C, STAND STOPPER

95011-63000

$3.90

21

BAND A, BATTERY

95012-11001

$2.92

22

BOLT, FLANGE (8X16)

95701-08016-07

$1.80

23

BOLT, FLANGE (8X45)

95801-08045-00
