Honda TRX250RA (89) FOURTRAX 250R, JPN, VIN# JH3TE120-KK300001 FRONT FENDER 88,89 Diagram

#

Description
Price

1

RUBBER, FUEL TANK SIDE

17503-HB9-771

Unavailable

2

RUBBER, FUEL TANK SETTING

17508-KA3-710

$8.75

3

COLLAR, HEADLIGHT SETTING

17509-HB9-770

Unavailable

4

GROMMET, FR. FENDER SETTING

19034-HB9-000

$5.26

5

COLLAR A, TAILLIGHT

33712-GC2-000

$3.04

6

GROMMET, IGNITION COVER

53133-KB4-000

$2.26

7

FENDER, R. FR. *NH138* (WOL) (SHASTA WHITE)

61100-HB9-305

Unavailable

7

FENDER, R. FR. *NH138* (WOL) (SHASTA WHITE) This part replaces 61100-HB9-306ZB.

61100-HB9-305

Unavailable

7

FENDER, R. FR. *NH138* (WOL) (SHASTA WHITE) This part replaces 61100-HB9-770ZC.

61100-HB9-305

Unavailable

8

STAY, R. FR. FENDER SETTING

61101-HB9-770

Unavailable

9

STAY, L. FR. FENDER SETTING

61102-HB9-670

Unavailable

10

STAY, R. FENDER RUBBER

61111-HB9-000

Unavailable

11

STAY, L. FENDER RUBBER

61112-HB9-000

Unavailable

12

METAL, FR. FENDER FIXING (LOWER)

61142-001-010

$3.03

13

FENDER, L. FR. *NH138* (WOL) (SHASTA WHITE)

61200-HB9-305ZB

Unavailable

13

FENDER, L. FR. *NH138* (WOL) (SHASTA WHITE) This part replaces 61200-HB9-770ZC.

61200-HB9-305ZB

Unavailable

14

COVER, FR. FENDER (LOWER)

61400-HB9-770

Unavailable

15

BAND, SIDE COVER

61502-HB9-000

Unavailable

16

COVER, FR. *NH138* (SHASTA WHITE)

61700-HB9-305ZB

Unavailable

16

COVER, FR. *NH138* (SHASTA WHITE) This part replaces 61700-HB9-770ZB.

61700-HB9-305ZB

Unavailable

17

LABEL, HELMET HOLDER (NOT AVAILABLE)

87511-VM6-680

Unavailable

18

BOLT, FLANGE (6MM)

90111-187-000

$5.59

19

NUT, SPRING (5MM)

90320-HB9-000

$3.12

20

SCREW, FR. FENDER (LOWER)

90322-HB9-770

Unavailable

21

SCREW, PAN (5X14)

93500-05014-0A

$1.49

22

NUT, FLANGE (8MM)

94050-08000

$1.49

23

BOLT, HEX. (6X38)

92101-06038-0B

Unavailable

24

BOLT, FLANGE (8X16)

96300-08016-00

$1.49
