Yamaha TR3 (TR3) 1972 FRONT WHEEL Diagram

#

Description
Price

1

HUB, FRONT

(240-25111-00-00)

Unavailable

2

SPOKE SET, FRONT

(240-25104-00-00)

Unavailable

3

RIM 1.60X18

(94416-18043-00)

Unavailable

3

RIM 1.85X18

(94418-18047-00)

Unavailable

5

TUBE

(94227-18010-00)

Unavailable

5

TUBE (5H5)

94227-18195-00

$35.99

6

BAND, RIM (2J4)

94340-18086-00

$17.99

7

SPACER(1ET)

90560-15290-00

$18.99

8

FLANGE, SPACER

146-25116-00-00

$8.99

9

BRG,R-B 6202Z 35MM 48G NT

93306-20204-00

$22.99

10

BRAKE SHOE

(240-25130-00-00)

Unavailable

11

SPRING, RETURN

(240-25133-00-00)

Unavailable

12

PLATE, BRAKE SHOE

(240-25121-00-00)

Unavailable

12

PLATE, BRAKE SHOE 2

(240-25169-00-00)

Unavailable

13

CIRCLIP (137)

93430-10015-00

$9.49

14

WASHER PLATE 341251470000

90201-25286-00

Unavailable

15

COVER, SUCTION

(240-25148-00-00)

Unavailable

16

COVER, PLATE

(240-25127-00-00)

Unavailable

17

SCREW, PAN HEAD (J10)

98580-03008-00

Unavailable

18

WASHER, SPRING

92990-03100-00

Unavailable

19

CAMSHAFT

(240-25151-00-00)

Unavailable

20

SPRING, TORSION

(90508-20026-00)

Unavailable

20

SPRING, TORSION

(90508-20027-00)

Unavailable

21

LEVER, CAMSHAFT 1

(240-25155-00-00)

Unavailable

22

LEVER, CAMSHAFT 2

(240-25156-00-00)

Unavailable

23

BOLT, HEXAGON

97017-06025-00

Unavailable

23

BOLT, FLAT HD.DRILL

(95201-06020-00)

Unavailable

24

WASHER, SPRING

92995-06100-00

Unavailable

25

AXLE, WHEEL

(240-25181-00-00)

Unavailable

26

NUT, CASTLE

(90171-15010-00)

Unavailable

27

PIN, COTTER

91490-30030-00

Unavailable

28

HOLDER, ADJUSTING

(240-26381-00-00)

Unavailable

29

CIRCLIP (EU0)

99080-04600-00

Unavailable

30

ROD, CONNECTING

(240-25161-00-00)

Unavailable

31

END, ROD 1

152-25163-00-00

Unavailable

32

END, ROD 2

152-25164-00-00

Unavailable

33

PIN, SPEC'L SHAPE

90249-06095-00

Unavailable

34

NUT(650)

95380-06700-00

Unavailable

35

BAR, TENSION

(328-25171-00-00)

Unavailable

36

BOLT, HEAD W/HOLE

(90103-08005-00)

Unavailable

37

YBS67-8 WASHER, SPRING

92990-08100-00

Unavailable

38

WASHER, PLATE

90201-15239-00

Unavailable

39

BALANCER, WHEEL

3HT-25398-00-00

Unavailable
