Suzuki TM250 (1975) FRAME COVER Diagram

#

Description
Price

1

PLATE, FRONT NUMBER | L,M

94910-16500

Unavailable

2

HOLDER, NUMBER PLATE | L,M

94950-28300

Unavailable

3

SCREW | L,M This part replaces 02141-06127.

02142-06127

$1.49

4

BAND | L,M

09462-00055

$6.09

5

EMBLEM, NUMBER PLATE FRONT | L

68169-16500

Unavailable

6

EMBLEM, NUMBER PLATE FRONT | M

68169-30400

Unavailable

7

COVER, FRAME RH | L,M

47111-30200

Unavailable

8

COVER, FRAME LH | L,M

47211-30200

Unavailable

9

SCREW | L,M This part replaces 02141-06127.

02142-06127

$1.49

10

LOCK WASHER | L This part replaces 08321-21068.

08321-01067

$2.13

11

SPACER, FRAME COVER RH | L,M

09169-06010

$2.60

12

SCREW | L,M

02141-06168

Unavailable

13

LOCK WASHER | L This part replaces 08321-21068.

08321-01067

$2.13

14

SPACER, FRAME COVER, FRONT | L,M

09169-06010

$2.60

15

NUT, FRAME COVER FRONT | L,M

08312-11068

Unavailable

16

EMBLEM, FRAME COVER RH | L This part replaces 68131-30200.

68131-30201

Unavailable

17

EMBLEM, FRAME COVER RH | M

68131-30201

Unavailable

18

EMBLEM, FRAME COVER LH | L This part replaces 68141-30200.

68141-30201

Unavailable

19

EMBLEM, FRAME COVER LH | M

68141-30201

Unavailable

20

EMBLEM, CCI | L,M

68171-26000

$3.59

21

LABEL, COMPANY NAME | L,M

68363-26200

Unavailable
