Kawasaki TERYX4™ S Throttle Diagram
#
Description
Price
11065
CAP
11065-0072
$7.20
14091
COVER,THROTTLE LINK
14091-1731
$22.78
16163
THROTTLE-ASSY,36EIS
16163-0790
$1,014.69
21176
SENSOR,PRESSURE
21176-0906
$222.28
49033
NOZZLE-INJECTION
49033-0011
$92.32
49056
PIPE-INJECTION
49056-0033
Unavailable
49116
VALVE-ASSY,ISC
49116-0021
$197.51
92009
SCREW,6X12
92009-1480
$3.21
92022
WASHER,5.2X13X1
92022-1380
$4.31
92037
CLAMP,TUBE
92037-1124
$6.11
92037A
CLAMP,L=45
92037-1539
$5.00
92055
RING-O,INJECTION NOZZLE
92055-1622
$1.95
92055A
RING-O,AIR SCREW
92055-1658
$6.00
92093
SEAL
92093-0082
$5.94
92093A
SEAL
92093-0127
$10.56
92144
SPRING,THROTTLE STOP SCREW
92144-1674
$5.74
92172
SCREW
92172-0156
$15.20
92191
TUBE,3.2X7.4X70
92191-1552
$4.14
92192
TUBE,ISC-CHAMBER
92192-0948
$12.80
92192A
TUBE,ISC-THROTTLE RR
92192-1211
$7.25
92192B
TUBE,ISC-THROTTLE FR
92192-1212
$10.62
92200
WASHER,PILOT AIR SCREW
92200-1564
$2.58
220
SCREW-PAN-CROS,4X8
220AA0408
$0.68
220A
SCREW-PAN-CROS,5X16
220AA0516
$2.06
220B
SCREW-PAN-CROS,6X12
220AA0612
$1.19
220C
SCREW-PAN-CROSS,6X14
220AA0614
$1.48
