Drive Shaft-Front
Kawasaki TERYX4™ S CAMO Drive Shaft-Front Diagram
#
11061
GASKET,10.5X16X3
11061-0805
$2.64
13107
SHAFT,CROSS
13107-0758
$29.06
13107A
SHAFT,6X55
13107-0759
$8.72
13107B
SHAFT,DIFF LOCK
13107-0768
$9.43
13107C
SHAFT
13107-0775
$12.29
13107D
SHAFT,ACTUATOR OUTPUT
13107-0776
$94.31
13139
SHIFTER
13139-0017
$77.69
13139A
SHIFTER,DIFF LOCK
13139-0018
$72.77
13140
FORK-SHIFT
13140-0070
$37.89
13140A
FORK-SHIFT
13140-0635
$34.52
13151
SWITCH-COMP
13151-1086
$38.19
13168
LEVER
13168-0731
$94.84
13216
GEAR-COMP,BEVEL,8T
13216-0884
$324.19
13272
PLATE
13272-0985
$14.62
13272A
PLATE
13272-0986
$6.00
14041
COVER-COMP,LH
14041-0575
$114.34
14055
CASE-GEAR,CROSS SHAFT
14055-0602
$225.94
14055A
CASE-GEAR,RH
14055-0626
$221.68
14092
COVER,CROSS SHAFT CASE
14092-1042
$178.74
16085
GEAR,65T
16085-0605
$116.83
16085A
GEAR,13T
16085-0614
$116.83
16146
COVER-ASSY,INPUT SHAFT
16146-0740
$127.23
16172
ACTUATOR
16172-0038
$637.73
49006
BOOT,INSIDE
49006-0578
$94.95
49006A
BOOT,OUTSIDE
49006-0638
$94.99
49022
GEAR-BEVEL,10T
49022-0579
$91.57
49022A
GEAR-BEVEL,16T
49022-0580
$155.00
49022B
GEAR-BEVEL,35T
49022-0607
$432.87
59266
JOINT-BALL,LH
59266-0744
$656.29
59266A
JOINT-BALL,RH
59266-0745
$656.29
92005
FITTING
92005-1142
$7.60
92022
WASHER,25.3X32X0.5
92022-225
$5.52
92033
RING-SNAP
92033-0837
$6.22
92037
CLAMP,TUBE
92037-1461
$3.88
92043
PIN,6.2X8X14
92043-1263
$0.43
92045
BEARING-BALL,60/28
92045-1176
$28.54
92046
BEARING-NEEDLE,AJ501907
92046-0025
$35.70
92046A
BEARING-NEEDLE
92046-0050
$29.90
92046B
BEARING-NEEDLE
92046-1234
$23.10
92049
SEAL-OIL,28X60X7
92049-0089
$16.97
92049A
SEAL-OIL
92049-0160
$12.92
92055
RING-O,7.5X1.5
92055-0756
$1.11
92055A
"O" RING
92055-081
$17.91
92055B
RING-O,35.8MM
92055-1281
$7.34
92065
GASKET,10.5X16X1
92065-058
$3.96
92066
PLUG,36X7.5
92066-0744
$8.22
92145
SPRING
92145-0975
$3.74
92150
BOLT,SOCKET,6X10
92150-1650
$4.31
92153
BOLT,FLANGED-SMALL,6X8
92153-0964
$2.24
92154
BOLT,FLANGED,10X23
92154-0550
$3.74
92170
CLAMP
92170-1925
$2.40
92172
SCREW,SET,85X11.5
92172-1122
$66.83
92180
SHIM,70X80X0.15
92180-0972
Unavailable
92180A
SHIM,70X80X0.2
92180-0973
Unavailable
92180B
SHIM,70X80X0.5
92180-0974
Unavailable
92180C
SHIM,70X80X0.8
92180-0975
Unavailable
92180D
SHIM,70X80X1.0
92180-0976
Unavailable
92180E
SHIM,70X80X1.2
92180-0977
Unavailable
92180F
SHIM,80X90X0.15
92180-0978
Unavailable
92180G
SHIM,80X90X0.2
92180-0979
Unavailable
92180H
SHIM,80X90X0.5
92180-0980
Unavailable
92180I
SHIM,80X90X0.8
92180-0981
Unavailable
92180J
SHIM,80X90X1.0
92180-0982
Unavailable
92180K
SHIM,80X90X1.2
92180-0983
Unavailable
92200
WASHER
92200-1077
$4.18
130
BOLT-FLANGED,10X14
130BA1014
$4.76
130A
BOLT-FLANGED,8X25
130CA0825
$1.46
130B
BOLT-FLANGED,10X30
130CA1030
$2.32
132
BOLT-FLANGED-SMALL,6X16
132BA0616
$1.51
132A
BOLT-FLANGED-SMALL,6X25
132BA0625
$2.80
132B
BOLT-FLANGED-SMALL,6X45
132BA0645
$4.45
481
CIRCLIP-TYPE-C,32MM
481J3200
$2.68
481A
CIRCLIP-TYPE-C,52MM
481J5200
$4.96
551
PIN-DOWEL,4X10
551A0410
$0.65
551A
PIN-DOWEL
551A1016
$2.96
601
BEARING-BALL
601B6010
$43.73
601A
BEARING-BALL
601B6011
$54.98
670
O RING
670D3022
$2.80
702
TUBE-RUBBER,5X8X930
702A05930
$8.01
