Kawasaki TERYX4™ Front Fender(s) Diagram

Description

Price

14093A

COVER,HOOD,S.BLACK

14093-0205-839

$177.02

14093B

COVER,FR GRILL

14093-0233

$203.24

35004

FENDER-FRONT,LH,M.M.WHITE

35004-0343-66F

$161.38

35004A

FENDER-FRONT,LH,N.YELLOW

35004-0343-66V

$158.33

35004C

FENDER-FRONT,RH,M.M.WHITE

35004-0344-66F

$161.57

35004D

FENDER-FRONT,RH,N.YELLOW

35004-0344-66V

$158.52

35004F

FENDER-FRONT,RR

35004-0345

$58.75

92009

SCREW,6X20

92009-1289

$4.31

92022

WASHER,12.5X22X1.2

92022-072

$3.92

92027

COLLAR

92027-4020

$4.65

92039

RIVET

92039-0776

$1.19

92071

GROMMET

92071-0746

$1.16

92077

KNOB

92077-0033

$3.04

92152

COLLAR,6.3X8.3X7.2

92152-1865

$1.19

92172

SCREW,TAPPING,6X16

92172-0739

$0.85

92172A

SCREW,6X16

92172-0826

$2.26

92172B

SCREW,TAPPING,6X20

92172-0883

$2.26

92210

NUT,LEAF SPRING,6MM

92210-0624

$2.32
