Frame Fittings(Rear)
Kawasaki TERYX4™ 750 4x4 (Canadian) Frame Fittings(Rear) Diagram
#
11056
BRACKET,FAN MOUNT
11056-1488
$20.16
14092
COVER,FR SEAT,RR,RH
14092-0714
$26.15
14092A
COVER,CENTER CONSOLE
14092-0715
$73.09
14092B
COVER,RR FLOOR,LH
14092-0718
$53.20
14092C
COVER,RR FLOOR,RH
14092-0719
$53.20
14092D
COVER,FR SEAT,RR,LH
14092-0722
$64.63
14092E
COVER,CENTER CONSOLE,TOP
14092-0791
$6.92
16073
INSULATOR,CENTER CONSOLE
16073-0710
$95.69
16073A
INSULATOR,CENTER CONSOLE
16073-0711
$32.96
16073B
INSULATOR,CENTER CONSOLE
16073-0712
$60.25
16073C
INSULATOR,CENTER CONSOLE
16073-0714
$15.62
16073D
INSULATOR,FR SEAT,RR
16073-0720
$18.77
16073E
INSULATOR,CENTER CONSOLE
16073-0721
$29.44
16073F
INSULATOR,RR FLOOR,LH
16073-0726
$10.88
16073G
INSULATOR,RR FLOOR,RH
16073-0727
$16.72
16073H
INSULATOR,FR SEAT,RR
16073-0728
$10.37
16073I
INSULATOR,FR SEAT,RR
16073-0733
$7.94
16073J
INSULATOR,FR SEAT,RR
16073-0734
$8.58
16073K
INSULATOR,FR SEAT,RR
16073-0735
$8.22
16073L
INSULATOR,CENTER CONSOLE
16073-0739
$50.89
16073M
INSULATOR,FR SEAT,RR
16073-0740
$8.08
16073N
INSULATOR,FR SEAT,RR
16073-0741
$8.22
16073O
INSULATOR,FR SEAT,RR
16073-0742
$11.20
16073P
INSULATOR,FR SEAT,RR
16073-0744
$6.93
16073Q
INSULATOR,CENTER CONSOLE
16073-0746
$30.04
16073R
INSULATOR,CENTER CONSOLE
16073-0747
$38.70
16073S
INSULATOR,FR SEAT,RR
16073-0749
$11.20
18018
PLATE-HEAT GUARD,UNDER CARRIER
18018-0554
$58.82
18018A
PLATE-HEAT GUARD,SIDE DUCT COV
18018-0574
$16.27
18018B
PLATE-HEAT GUARD,BULKHEAD
18018-0576
$70.21
18018C
PLATE-HEAT GUARD,FAN DUCT
18018-0577
$108.95
18018D
PLATE-HEAT GUARD,RR TUNNEL
18018-0580
$133.88
18018E
PLATE-HEAT GUARD,RR PLATE
18018-0581
$87.04
18018F
PLATE-HEAT GUARD,DRIVER SIDE
18018-0583
$60.42
59502
FAN-ASSY,BLOWER
59502-0560
$444.24
92009
SCREW,6X25
92009-1465
$3.92
92015
NUT,RUBBER,6MM
92015-1692
$7.34
92039
RIVET
92039-1229
$1.19
130
BOLT-FLANGED,6X10
130AA0610
$0.49
130A
BOLT-FLANGED,6X22
130BA0622
$1.29
92043
PIN,WINGED
92043-0739
$6.47
92072
BAND,L=140
92072-1293
$7.11
92143
COLLAR
92143-1087
$4.31
92145
SPRING
92145-0905
$1.44
92145A
SPRING,CLIP
92145-0906
$2.35
92161
DAMPER
92161-0580
$2.40
92161A
DAMPER,20X37.5X1.6
92161-1486
$2.02
92172
SCREW,6X16
92172-0711
$3.02
92172A
SCREW,TAPPING,6X16
92172-0739
$0.85
92173
CLAMP
92173-0933
$7.58
92200
WASHER
92200-0800
$0.79
92200A
WASHER,6.5X22X1.6
92200-1087
$3.94
