Kawasaki TERYX® KRX4™ 1000 LIFTED EDITION Seat(Rear) Diagram

Description

Price

31064

PIPE-COMP,RR,SEAT SUPPORT

31064-0742

$30.93

53007

FRAME-SEAT

53007-0446

$116.87

53045

HOOK-ASSY,SEAT BACK

53045-0037

$16.99

53045A

HOOK-ASSY,SEAT BOTTOM

53045-0039

$25.26

53061

BELT-SEAT,BUCKLE

53061-0039

$31.80

53061A

BELT-SEAT,RETRACTOR

53061-0369

$156.61

53066

SEAT-ASSY,BOTTOM,BLACK+GRN

53066-0975-71R

$360.08

53066A

SEAT-ASSY,BACK,GREEN+BLK+SIL

53066-0976-61Z

$501.57

92145

SPRING,SEAT LATCH

92145-0022

$7.15

92145A

SPRING

92145-2235

$5.41

92154

BOLT,FLANGED,10X16

92154-2089

$7.35

92161

DAMPER,SEAT

92161-1489

$3.35

92161A

DAMPER,10X34X10

92161-1920

$1.59

92200

WASHER,10.3X23X1.6

92200-0724

$3.74

130

BOLT-FLANGED,8X14

130BA0814

$2.16

130A

BOLT-FLANGED,8X40

130BA0840

$1.98

130B

BOLT-FLANGED,12X18

130BA1218

$2.80

130C

BOLT-FLANGED,12X22

130BA1222

$3.04

130D

BOLT-FLANGED,10X20

130CA1020

$2.13
