Kawasaki TERYX® KRX4™ 1000 LIFTED EDITION Brake Pedal/Throttle Lever Diagram

Description

Price

11057

BRACKET,BRAKE PEDAL

11057-2099

$39.14

14093

COVER,SWITCH

14093-1021

$1.95

27010

SWITCH,BRAKE

27010-0724

$30.46

39075

LEVER-THROTTLE

39075-0033

$114.43

43001

LEVER-BRAKE

43001-0767

$46.70

43106

LEVER-ASSY-PARKING BRAKE

43106-0013

$81.27

92028

BUSHING

92028-1571

$10.27

92043

PIN,16X78

92043-0917

$13.88

92043A

92043-1039

$7.54

92072

BAND,L=292.1

92072-3509

Unavailable

92145

SPRING

92145-1849

$10.86

92145A

SPRING

92145-1884

$8.39

92200

WASHER,16X26X2.3

92200-0043

$5.84

92200A

WASHER,8.5X17X0.8

92200-0993

$3.74

130

BOLT-FLANGED,8X40

130BA0840

$1.44

130A

BOLT-FLANGED,8X18

130CA0818

$1.81

130B

BOLT-FLANGED,8X22

130CB0822

$1.74

317

NUT-HEX-SMALL,8MM

317BA0800

$1.24

550

PIN-COTTER,2.5X25

550AA2525

$1.05

554

PIN-SNAP,10MM

554DA1000

$0.73
