Kawasaki Teryx KRX®4 1000 eS Seat(Rear) Diagram

Description

Price

31064

PIPE-COMP,RR,SEAT SUPPORT

31064-0742

$31.50

53007

FRAME-SEAT

53007-0446

$119.21

53045

HOOK-ASSY,SEAT BACK

53045-0037

$15.97

53045A

HOOK-ASSY,SEAT BOTTOM

53045-0039

$23.66

53061

BELT-SEAT,BUCKLE

53061-0039

$27.99

53061A

BELT-SEAT,RETRACTOR

53061-0369

$159.72

53066

SEAT-ASSY,BOTTOM,BLACK+BLK

53066-0825-71Q

$367.20

53066A

SEAT-ASSY,BACK,GRAY+BLK+SIL

53066-0826-71T

$532.27

92145

SPRING,SEAT LATCH

92145-0022

$5.43

92145A

SPRING

92145-2235

$4.76

92154

BOLT,FLANGED,10X16

92154-2089

$7.25

92161

DAMPER,SEAT

92161-1489

$2.31

92161A

DAMPER,10X34X10

92161-1920

$1.20

92200

WASHER,10.3X23X1.6

92200-0724

$2.84

130

BOLT-FLANGED,8X14

130BA0814

$1.54

130A

BOLT-FLANGED,8X40

130BA0840

$1.44

130B

BOLT-FLANGED,12X18

130BA1218

$2.29

130C

BOLT-FLANGED,12X22

130BA1222

$2.46

130D

BOLT-FLANGED,10X20

130CA1020

$1.76
