Kawasaki TERYX KRX® 1000 eS Guards/Cab Frame Diagram

#

Description
Price

13272

PLATE,SKID,FR,LH

13272-2638

$71.37

13272A

PLATE,SKID,FR,RH

13272-2639

$71.37

13272B

PLATE,DRIVE SHAFT

13272-2642

$59.45

13272C

PLATE,SKID,FR,CNT,LH

13272-2737

$80.99

13272D

PLATE,SKID,FR,CNT,RH

13272-2738

$80.99

13272E

PLATE,CVT COVER

13272-3797

$26.18

14093

COVER,SKID,CNT

14093-0811

$43.65

14093A

COVER,SKID,RR

14093-0877

$45.16

18018

PLATE-HEAT GUARD

18018-0616

$33.59

18018A

PLATE-HEAT GUARD

18018-0617

$25.79

39043

CROSSMEMBER-COMP,FR,T.P.RED

39043-0031-66S

$197.08

39043A

CROSSMEMBER-COMP,RR,T.P.RED

39043-0032-66S

$158.46

55047

BAR-COMP,A-PILLAR,LH,T.P.RED

55047-0378-66S

$168.59

55047A

BAR-COMP,A-PILLAR,RH,T.P.RED

55047-0379-66S

$168.59

55047B

BAR-COMP,B-PILLAR,LH,T.P.RED

55047-0380-66S

$123.01

55047C

BAR-COMP,B-PILLAR,RH,T.P.RED

55047-0381-66S

$123.01

55047D

BAR-COMP,C-PILLAR,LH,T.P.RED

55047-0382-66S

$192.38

55047E

BAR-COMP,C-PILLAR,RH,T.P.RED

55047-0383-66S

$192.38

92009

SCREW,TAPPING,6X16

92009-1166

$5.52

92015

NUT,LOCK,FLANGED,12MM

92015-1433

$8.86

92022

WASHER,6.5X24X2

92022-1690

$3.92

92022A

WASHER

92022-2247

$0.62

92152

COLLAR

92152-0784

$2.12

92152A

COLLAR,6.3X9.5X4.1

92152-1571

$6.00

92154

BOLT,FLANGED,6X12

92154-2922

$1.94

92154A

BOLT,FLANGED,12X45

92154-4096

$7.78

92154B

BOLT,FLANGED,6X10

92154-4159

$1.59

92161

DAMPER,10X85X1

92161-1964

$3.21

92172

SCREW,TAPPING,6X16

92172-0869

$1.48

92200

WASHER,6.5X20X1.6

92200-0283

$1.40

130

BOLT-FLANGED,6X12

130CA0612

$3.96

130A

BOLT-FLANGED,12X16

130CA1216

$2.75

130B

BOLT-FLANGED,12X25

130CA1225

$7.74

130C

BOLT-FLANGED,12X35

130CA1235

$3.63
