Frame Fittings(Rear)
Kawasaki Teryx® 750 FI 4x4 NRA Outdoors Frame Fittings(Rear) Diagram
#
11055
BRACKET
11055-0419
$2.78
11055A
BRACKET
11055-0896
$4.34
11055B
BRACKET
11055-1384
$7.09
11055C
BRACKET,SEAT LOCK PLATE,RH
11055-1409
$51.56
11055D
BRACKET,SEAT LOCK
11055-1814
$55.04
13272
PLATE
13272-0318
$8.34
13272A
PLATE
13272-0351
$14.06
13272B
PLATE,TUNNEL PLATE
13272-0421
$44.08
13272C
PLATE
13272-0434
$28.78
13272D
PLATE,HEAT GUARD
13272-0731
$50.52
13272E
PLATE,BATTERY HOLDER
13272-0748
$42.37
14091
COVER,CONSOLE CENTER,F.BLACK
14091-0975-6Z
$51.08
14091A
COVER,SEAT,F.BLACK
14091-0982-6Z
$74.21
14091B
COVER,CONSOLE CENTER,F.BLACK
14091-1724-6Z
Unavailable
14091C
COVER,ELECTRIC
14091-1761
$24.49
14091D
COVER,HEAT
14091-1805
$37.06
16073
INSULATOR,CENTER CONSOLE,RH
16073-0092
$65.21
16073A
INSULATOR,SEAT BRACKET
16073-0097
$7.95
16073B
INSULATOR,AIR CLEANER,UPP
16073-0102
$64.62
16073C
INSULATOR,CENTER CONSOLE,LH
16073-0103
$64.62
16073D
INSULATOR,CENTER CONSOLE,UPP
16073-0104
$34.26
16073E
INSULATOR,LEG COVER,CNT,UPP
16073-0105
$23.80
16073F
INSULATOR,LEG COVER,CNT,RH,LWR
16073-0106
$53.19
16073G
INSULATOR,LEG COVER,CNT,LH,LWR
16073-0107
$53.19
16073H
INSULATOR,LEG COVER,CNT,LH,UPP
16073-0108
$28.75
16073I
INSULATOR,EXHAUST PIPE
16073-0112
$19.93
16073J
INSULATOR,EXHAUST PIPE
16073-0113
$5.40
31064
PIPE-COMP
31064-0181
$47.32
31064A
PIPE-COMP
31064-0194
$143.14
39145
TRIM-SEAL,L=53
39145-0035
$4.72
39145A
TRIM-SEAL,L=120
39145-0040
Unavailable
59416
CASE-ELECTRIC
59416-0018
$31.89
92002
BOLT,FLANGED,10X46
92002-1740
$7.69
92009
SCREW,TAPPING,6X16
92009-1166
$5.52
92009A
SCREW,6X22,BLACK
92009-1256
$2.78
92009B
SCREW,6X16
92009-1621
Unavailable
92015
NUT,FLANGED,8MM
92015-1406
$4.45
92022
WASHER,6.5X16X1.0
92022-1093
$2.08
92039
RIVET
92039-0046
$3.90
92039A
RIVET
92039-0086
$5.54
130
BOLT-FLANGED,5X10
130BA0510
$1.71
130A
BOLT-FLANGED,8X18
130BA0818
$2.55
130B
BOLT-FLANGED,6X12
130BB0612
$2.34
130C
BOLT-FLANGED,6X14
130BB0614
$2.49
130D
BOLT-FLANGED,6X16
130BB0616
$2.06
130E
BOLT-FLANGED,6X20
130BB0620
$0.46
130F
BOLT-FLANGED,10X20
130BB1020
$5.96
130G
BOLT-FLANGED,8X20
130CA0820
$1.71
92039B
RIVET
92039-1229
$1.19
92072
BAND,BATTERY,UPP
92072-0128
$16.81
92143
COLLAR
92143-1057
$5.00
92143A
COLLAR
92143-1087
$4.31
92152
COLLAR,10.22X12.7X158.8
92152-0794
$17.78
92153
BOLT,FLANGED,10X38
92153-1742
$10.79
92154
BOLT,BATTERY
92154-0137
$18.48
92161
DAMPER
92161-0273
$1.78
92161A
DAMPER
92161-0578
$4.25
92161B
DAMPER
92161-0579
$2.52
92170
CLAMP
92170-1925
$2.40
92210
NUT,POP,10MM
92210-0507
$4.71
92210A
NUT,LOCK,FLANGED,10MM
92210-1080
$10.28
