Kawasaki TERYX® 750 FI 4x4 LE (SGE) Frame Fittings(Rear) Diagram

#

Description
Price

11055

BRACKET

11055-0419

$2.78

11055A

BRACKET

11055-0896

$4.34

11055B

BRACKET

11055-1384

$7.09

11055C

BRACKET,SEAT LOCK PLATE,RH

11055-1409

$51.56

11055D

BRACKET,SEAT LOCK PLATE,LH

11055-1921

$51.56

13272

PLATE

13272-0318

$8.34

13272A

PLATE,TUNNEL PLATE

13272-0421

$44.08

13272B

PLATE

13272-0434

$28.78

13272C

PLATE,HEAT GUARD

13272-0731

$50.52

13280

HOLDER,BATTERY

13280-0361

$18.77

14091

COVER,CONSOLE CENTER,F.BLACK

14091-0975-6Z

$51.08

14091A

COVER,SEAT,F.BLACK

14091-0982-6Z

$74.21

14091B

COVER,CONSOLE CENTER,F.BLACK

14091-1724-6Z

Unavailable

14091C

COVER,ELECTRIC

14091-1761

$24.49

14092

COVER,HEAT

14092-0051

$36.39

16073

INSULATOR,SEAT BRACKET

16073-0097

$7.95

16073A

INSULATOR,EXHAUST PIPE

16073-0112

$19.93

16073B

INSULATOR,EXHAUST PIPE

16073-0113

$5.40

16073C

INSULATOR,A/C,UPP

16073-0115

$58.83

16073D

INSULATOR,CONSOLE,LH

16073-0116

$59.94

16073E

INSULATOR,CONSOLE,RH

16073-0117

$58.26

16073F

INSULATOR,CONSOLE,UPP

16073-0118

$32.29

16073G

INSULATOR,UPP

16073-0119

$29.64

16073H

INSULATOR,RH

16073-0120

$53.96

16073I

INSULATOR,LH,LWR

16073-0121

$53.96

16073J

INSULATOR,LH,UPP

16073-0122

$26.13

31064

PIPE-COMP,SHIFT

31064-0193

$136.61

31064A

PIPE-COMP,SEAT RAIL

31064-0201

Unavailable

39145

TRIM-SEAL,L=120

39145-0040

Unavailable

59416

CASE-ELECTRIC

59416-0018

$31.89

92002

BOLT,FLANGED,10X46

92002-1740

$7.69

92009A

SCREW,6X22,BLACK

92009-1256

$2.78

92022

WASHER,6.5X16X1.0

92022-1093

$2.08

92039

RIVET

92039-0046

$3.90

92039A

RIVET

92039-0086

$5.54

92039B

RIVET

92039-1229

$1.19

92072

BAND,BATTERY,UPP

92072-0128

$16.81

130

BOLT-FLANGED,5X10

130BA0510

$1.71

130A

BOLT-FLANGED,6X12

130BA0612

$1.72

130B

BOLT-FLANGED,6X14

130BA0614

$1.20

130C

BOLT-FLANGED,6X16

130BA0616

$1.20

130D

BOLT-FLANGED,8X18

130BA0818

$2.55

130E

BOLT-FLANGED,10X20

130BA1020

$3.35

130F

BOLT-FLANGED,10X20

130BB1020

$5.96

130G

BOLT-FLANGED,8X20

130CA0820

$1.71

92143

COLLAR

92143-1057

$5.00

92143A

COLLAR

92143-1087

$4.31

92151

BOLT,8X177

92151-1788

$19.30

92152

COLLAR,10.22X12.7X158.8

92152-0794

$17.78

92153

BOLT,FLANGED,10X38

92153-1742

$10.79

92161

DAMPER

92161-0273

$1.78

92161A

DAMPER

92161-0578

$4.25

92161B

DAMPER

92161-0579

$2.52

92170

CLAMP

92170-1925

$2.40

92171

CLAMP

92171-0453

$3.54

92172

SCREW,6X16

92172-0236

$0.85

92172A

SCREW,TAPPING,6X16

92172-0739

$0.85

92210

NUT,10MM

92210-0573

$10.86

92210A

NUT,LOCK,FLANGED,10MM

92210-1080

$10.28
