Suzuki TC125J (1975) SEAT Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE | L,M; TO 45100-20400-483 This part replaces 45100-28000-403.

45100-28831-865

Unavailable

1

SEAT ASSY | J; TO 45160-28401-403

45100-28400-403

Unavailable

1

SEAT ASSY | K

45100-28601-403

Unavailable

2

PIN,SEAT SUPPORT

09200-06018

$2.06

3

.COTTER PIN This part replaces 04111-20158.

04111-2015A

$1.49

4

CLAMP, SEAT | L,M; TO 45211-26001 This part replaces 45210-26000.

45211-26001

Unavailable

5

BUSHING,SEAT CLAMP | L,M

09319-08007

Unavailable

6

CLAMP, SORT

45211-26001

Unavailable

7

BOSS,SEAT CLAMP

45210-26001

Unavailable

8

SPRAT, SEAT CLAMP

09448-17007

Unavailable

9

BOLT

01102-08458

Unavailable

10

LOCK WASHER

08321-21630

Unavailable

11

NUT

08312-11068

Unavailable

12

CUSHION, SEAT

09321-08006

$2.90

13

CUSHION, SEAT

09321-10002

$2.22

14

CARRIER, SPORT

46310-28400

Unavailable

15

BOLT This part replaces 01122-10168.

01500-10167

$3.85

16

WASHER | L,M,J

04522-21108

Unavailable

17

LOCK WASHER | L,M,J

08321-21100

Unavailable
