Suzuki TC125J (1975) FUEL TANK Diagram

#

Description
Price

1

TANK, FUEL | J; TO 43100-28860-616

44110-28600-616

Unavailable

2

TANK, FUEL | J; TO 44100-28000-157; Includes Item(s) 3

44100-28860-616

Unavailable

3

CAP ASSY,FUEL T | J This part replaces 44200-33011.

44200-33012

Unavailable

4

EMBLEM | J; Includes Item(s) 5

68111-28600

Unavailable

5

NUT | J

09148-04005

Unavailable

6

TANK, FUEL | K; Includes Item(s) 7 - 8

44110-28826-709

Unavailable

7

NO DESCRIPTION AVAILABLE | K This part replaces 68115-28000-002.

68100-28870-002

Unavailable

8

NO DESCRIPTION AVAILABLE | K This part replaces 68125-28000-002.

68100-28870-002

Unavailable

9

EMBLEM, FUEL TANK CENTER | K

68118-14100-002

Unavailable

10

NO DESCRIPTION AVAILABLE | L; Includes Item(s) 11 - 14 This part replaces 44110-28400-714.

44110-28690-737

Unavailable

11

EMBLEM,RH | L

68111-28400-742

Unavailable

12

EMBLEM,LH | L

68121-28400-742

Unavailable

13

NO DESCRIPTION AVAILABLE | L This part replaces 68115-28400-002.

68100-28830-002

Unavailable

14

NO DESCRIPTION AVAILABLE | L This part replaces 68125-28400-002.

68100-28850-722

Unavailable

15

NO DESCRIPTION AVAILABLE | M; Includes Item(s) 16 - 17 This part replaces 44110-28650-797.

44110-28690-737

Unavailable

16

NO DESCRIPTION AVAILABLE | M This part replaces 68115-25600-991.

68100-25860-991

Unavailable

17

NO DESCRIPTION AVAILABLE | M This part replaces 68125-25600-991.

68100-25860-991

Unavailable

18

CAP FUEL TANK | J; Includes Item(s) 19 This part replaces 44210-12000.

44200-23810

$49.39

19

GASKET, FUEL TANK CAP | J

44248-12000

Unavailable

20

CAP ASSY, FUEL TANK | K; TO 44200-33011

44200-33019

Unavailable

20

CAP ASSY,FUEL T | L,M; Includes Item(s) 21 - 21 This part replaces 44200-33011.

44200-33012

Unavailable

21

GASKET, FUEL TANK CAP | K; TO 44246-33011

44248-33010

Unavailable

21

CAP ASSY,FUEL T | L,M This part replaces 44200-33011.

44200-33012

Unavailable

22

WASHER | K,L,M

44238-33010

Unavailable

23

PIN, TANK CAP FRONT | K,L,M

44239-33010

Unavailable

24

PIN, TANK CAP ROCK | K,L,M; Includes Item(s) 25

44233-33010

Unavailable

25

E RING | K,L,M

09383-02003

Unavailable

26

CLIP, FUEL TANK | J

68111-18600

Unavailable

27

EMBLEM, FUEL TANK | K

68111-18600

Unavailable

28

SCREW | J This part replaces 02131-03067.

02122-03067

$1.80

29

NUT, FUEL TANK EMBLEM | K

09148-04005

Unavailable

30

COCK ASSY FUEL | J,K,L; TO 44300-28071 This part replaces 44300-28070.

44300-28604

Unavailable

30

COCK ASSY FUEL | M; Includes Item(s) 31 - 35 This part replaces 44300-28071.

44300-28604

Unavailable

31

COCK ASSY FUEL This part replaces 44300-28071.

44300-28604

Unavailable

32

O-RING This part replaces 44346-28070.

44346-28071

$2.40

33

GASKET,LEVER | M This part replaces 44341-28070.

44341-28071

$2.92

34

CLEANER

44344-26040

Unavailable

35

SCREW This part replaces 09128-06005.

02162-0616B

$2.03

36

GASKET (5.8X13X1.2) This part replaces 09168-06010.

09168-06023

$2.35

37

.HOSE (3X7X600) | L:150 This part replaces 09343-03018.

09355-30001-600

$8.56

38

CLIP,FUEL HOSE

09401-08401

$1.54

39

CUSHION This part replaces 09329-10007.

09329-10026

$2.23

40

CUSHION, FUEL TANK REAR

44541-28000

$6.68

41

BAND,FUEL TANK FRONT | J

09462-00047

Unavailable

41

BAND,FUEL TANK FRONT | K,L,M

09462-00007

$4.11

42

BAND,FUEL TANK REAR

09462-00042

Unavailable
