Suzuki T500J (1975) REAR SWINGING ARM Diagram

#

Description
Price

1

FOOTREST SET,PI | R,J,K,L,M This part replaces 43600-10808.

43600-10809

Unavailable

1

FOOTREST ASSY, PILLION | R,J,K,L,M; Includes Item(s) 2

43610-03001

$6.52

2

NUT | R,J,K,L,M This part replaces 08312-11108.

08310-00107

$2.19

3

LOCK WASHER | R,J,K,L,M This part replaces 08321-21108.

08321-01107

$1.84

4

SHAFT, PIVOT | R,J,K; L:242 TO 6121:-15004

61211-15003

Unavailable

4

SHAFT, PIVOT | L

61211-15004

Unavailable

4

SHAFT, REAR SWINGING ARM | M This part replaces 61211-15005.

61211-15007

Unavailable

5

WASHER | R,J,K,L,M This part replaces 08322-11148.

08322-01147

$1.91

6

NUT, PIVOT SHAFT | R,J,K,L,M

09159-14003

Unavailable

7

SHOCK ABSORBER ASSY, REAR | R,J,K,L

62100-15110

Unavailable

7

SHOCK ABSORBER ASSY, REAR | M; Includes Item(s) 8

62100-18601

Unavailable

8

SPRING | R; CHROME-PLATED

62211-15110

Unavailable

9

NUT | R,J,K,L,M This part replaces 08313-11107.

08313-10107

$2.50

10

WASHER | R,J,K,L,M This part replaces 08322-11128.

08322-01127

$1.84

11

WASHER, LOWER (10.5X24X2.3) | R,J,K,LM This part replaces 09160-10001.

09160-10093

$2.35

12

NO DESCRIPTION AVAILABLE | R,J,K,L,M; CHROME-PLATED This part replaces 61310-15100.

61310-15102

Unavailable

13

SCREW, HEADLAMP (5X12) | R,J,K,L,M This part replaces 02121-05127.

09126-05003

$2.06

14

WASHER,LOCK | R,J,K,L,M This part replaces 08323-31058.

08323-3105A

$1.49

15

BOLT | R,J,K,L,M This part replaces 01112-06128.

01500-06127

$1.97

16

LOCK WASHER | R,J,K,L,M This part replaces 08321-21068.

08321-01067

$2.13

17

SWINGING ARM ASSY | R,J,K,L

61103-15810-019

Unavailable

17

NO DESCRIPTION AVAILABLE | M; Includes Item(s) 18 - 20 This part replaces 61100-15830-019.

61100-15831-019

Unavailable

18

SPACER | R,J,K,L,M; ID:15.3, L:99.2

61280-15000

Unavailable

19

BUSHING | R,J,K,L,M; ID:22, L:40 This part replaces 09307-22002.

09307-22003

Unavailable

20

NIPPLE, GREASE | R,J,K,L,M This part replaces 08351-31008.

08351-3100A

$4.45

21

SPACER | R,J,K,L,M; 14x22x41.5 This part replaces 61251-15000.

61251-15001

Unavailable

22

THRUST WASHER | R,J,K,L,M; 14.5x29x2.3

09160-14009

$2.82

23

.O RING (D:3,ID:29.5) | R,J,K,L,M; ID:29.5, D.:3.0

09280-30001

$1.72

24

COVER, DUST | R,J,K,L,M

61262-15000

$93.03

25

TORQUE LINK, REAR | R,J,K,L,M

64310-15000

Unavailable

26

BOLT, TORQUE LINK | R,J,K,L,M; 10x28

09101-10003

Unavailable

27

NUT | R,J,K,L,M This part replaces 08311-11108.

08310-00107

$2.19

28

LOCK WASHER | R,J,K,L,M This part replaces 08321-21108.

08321-01107

$1.84

29

SPRING, TORQUE LINK | R,J,K,L,M

09440-18002

$1.49

30

CLIP | R,J,K,L,M This part replaces 09385-10001.

09385-10005

$1.56
