Suzuki T305 (1969) PISTON - CRANKSHAFT Diagram

#

Description
Price

1

02 CRANKSHAFT ASSY | 1 TC305

12000-183

Unavailable

2

PISTON | TC305

12110-18000

Unavailable

2

PISTON | TC305; OS 0.5, OPT

12110-18700

Unavailable

2

PISTON | TC305; OS 1.0, OPT

12110-18710

Unavailable

3

PISTON RING SET | TC305

12140-18030

Unavailable

3

PISTON RING SET | TC305; OS 0.5, OPT

12140-18700

Unavailable

3

NO DESCRIPTION AVAILABLE | TC305; OS 1.0, OPT This part replaces 12140-18720.

12140-18110-050

Unavailable

4

PIN, PISTON | TC305; LD=12.5(0.49) OD=16(0.63) W=49.5(1.95) This part replaces 12151-18000.

12151-60D00

$17.37

5

CONNECTING ROD | TC305

12161-18000

Unavailable

6

PIN, CRANK | TC305 This part replaces 12211-18000.

12211-18001

Unavailable

7

RIGHT CRANKSHAFT | TC305

12220-18000

Unavailable

8

CENTER CRANKSHAFT | TC305

12231-18000

Unavailable

9

RIGHT CRANK WHEEL | TC305

12240-18000

Unavailable

10

LEFT CRANK WHEEL | TC305

12250-18000

Unavailable

11

LEFT CRANKSHAFT | TC305

12260-18000

Unavailable

12

OIL GRADE PLATE | TC305

12511-18000

Unavailable

13

PRIMARY DRIVE GEAR | TC305; NT=20

21111-18000

Unavailable

14

DOWEL PIN

04221-04149

Unavailable

15

WASHER, SUB T/M DRIVE This part replaces 08211-25401.

09181-25251

$3.87

16

KEY

08341-31039

$1.89

17

KEY

08341-31059

$2.48

18

PRIMARY DRIVE GEAR NUT | TC305; 12SCREW

09159-12103

Unavailable

19

WASHER | TC305; LD=20(0.79) OD=34(1.34) T=1.0(0.04) This part replaces 09160-20010.

09160-20052

$5.68

20

PRIMARY DRIVE GEAR WASHER | TC305; OD=30(1.18) T=0.8(0.03)

09166-12002

Unavailable

21

PRIMARY DRIVE GEAR SPACER | TC305; @

09180-25014

Unavailable

22

NO DESCRIPTION AVAILABLE | TC305; @ This part replaces 09262-25008.

09262-25009

Unavailable

23

RN 16X21X19.6BR | TC305TC305 This part replaces 09263-16004.

09263-16015

$15.54

24

BEARING, CRANK PIN | TC305; @ This part replaces 09263-20001.

09263-20020

$20.60

25

B1 25X62X17 BEA | TC305; @ This part replaces 09269-25004.

09269-25005

Unavailable

26

CENTER CRANKSHAFT OIL SEAL | TC305; @

06283-25017

Unavailable

27

LEFT CREAFTSHAFT OIL SEAL | TC305; @

09283-25019

$18.77

28

RIGHT CRAFTSHAFT OIL SEAL | TC305; @

09283-32001

Unavailable

29

PISTON PIN CIRCLIP | TC305

09381-16001

$1.67

30

RIGHT CRAFTSHAFT BEARING | TC305TC305

09390-65002

Unavailable
