Suzuki T305 (1969) OIL PUMP - OIL HOSE Diagram

#

Description
Price

1

OIL HOSE | TC305

11441-18000

Unavailable

2

OIL PUMP LEVER PIN | TC305

13683-51010

Unavailable

3

OIL PUMP ASS'Y | TC305

18000-18303

Unavailable

4

OIL PUMP DRIVE SHAFT COMP. | TC305

16520-18000

Unavailable

5

OIL PUMP DRIVE GASE | TC305

16331-18000

Unavailable

6

OIL PUMP GEAR CASE | TC305

16341-18000

Unavailable

7

OIL PUMP GEAR CASE GASKET | TC305

16381-18000

Unavailable

8

OIL PUMP GASKET | TC305

16731-11000

Unavailable

9

OIL HOSE NO.1 | TC305

16810-18030

Unavailable

10

OIL HOSE NO.2 | TC305

16820-18030

Unavailable

11

OIL HOSE NO.3 | TC305

16840-18030

Unavailable

12

CROSS HEAD SCREW

02111-05128

Unavailable

13

SCREW This part replaces 02111-06128.

02112-06127

$1.84

14

CROSS HEAD SCREW

02111-06108

Unavailable

15

CROSS HEAD SCREW

02111-06208

Unavailable

16

WASHER, CLUTCH RELEASE This part replaces 08211-10201.

09181-10195

$1.99

17

WASHER This part replaces 08322-21088.

08322-01087

$2.13

18

GASKET | TC305 ID=6.2(0.62) OD=12(0.47) W=1.5(0.05) This part replaces 09168-06002.

09168-06004

$1.49

19

OIL PUMP DRIVE SHAFT BUSHING N | TC305 ID=10(0.39) L=11(0.43)

09301-10002

Unavailable

20

OIL PUMP DRIVE SHAFT BUSHING N | TC305 ID=10(0.39) L=14(0.55)

05319-10006

Unavailable

20

O.2

09319-10006

Unavailable

21

OIL PUMP UNION BOLT | TC305

09360-06003

$3.76

22

A.C.GENERATOR READ WIER CLAMP | TC305

09403-00007

Unavailable
