Can-Am Defender - HD10 - DPS - 8BTF - Compass Green - 64" Width, 2026 Suspension - Front Components Diagram

LH Upper Suspension Arm Ass'y With Balljoint This part replaces 706204077.

715010603

$259.99

RH Upper Suspension Arm Ass'y With Balljoint This part replaces 706204078.

715010604

$259.99

Suspension Arm Bushing Kit | Includes 4

703500875

$16.33

Suspension Arm Bushing Kit | Includes 4

703500875

$16.33

Suspension Arm Bushing Kit | Includes 4

703500875

$16.33

Grease Fitting

408200700

$3.49

LH Lower Suspension Arm Ass'y With Balljoint

715010599

$259.99

RH Lower Suspension Arm Ass'y With Balljoint This part replaces 706203996.

715010600

$259.99

Hex. Flange Screw M10 X 70

207607046

$2.96

Hex. Flange Elastic Nut M10

233201436

$2.11

Ball Joint

706203084

$35.99

Ball Joint

706202045

$35.99

Black, Pop Rivet 3/16 X ,550

293150292

$1.05

RH CV joint Guard

706202135

$11.01

LH CV joint Guard

706202134

$11.01

LH Knuckle

706205046

$201.49

RH Knuckle

706205047

$201.49

Circlip

293370035

$2.64

Hex Nut M12

250100239

$2.00

Hardened Washer

706200281

$2.85

Cotter Pin

211400017

$0.33

Hex. Flange Screw M10 X 55

207605546

$2.11
