Description

Price

1

SPACER ASSY., RR. COVER

11310-HL6-A00

$526.25

2

COVER, SPACER

11322-HL4-000

$8.48

3

O-RING, SPACER COVER

11323-HL4-000

$2.69

4

PIN, OIL GUIDE (10MM)

11334-HN8-010

$9.89

5

GASKET, RR. SPACER COVER

11394-HL4-003

$16.90

6

ROTOR SET A, OIL PUMP

15020-HL4-000

$38.26

7

ROTOR SET B, OIL PUMP

15030-HL4-003

$41.11

8

ROTOR SET C, OIL PUMP

15040-HL4-000

$43.08

9

BODY, OIL PUMP

15101-HL4-000

$53.34

10

PLATE, OIL PUMP | Use up to Engine SN 8218206.

15102-HL4-000

$25.43

10

PLATE, OIL PUMP | Use from Engine SN 8218207.

15102-HL4-010

Unavailable

11

JOINT, LINE (DCT)

15104-HL4-000

$6.51

12

JOINT, FEED LINE

15105-HL4-000

$8.80

13

RING, BACK-UP (16X20)

15107-HL4-000

$3.74

14

RING, BACK-UP (12X15)

15108-HL4-000

$3.05

15

COVER, OIL PUMP

15110-HL4-000

$74.82

16

SHAFT, OIL PUMP

15111-HL4-000

$39.56

17

BOLT, SEALING (24MM)

15234-MGS-D20

$6.13

18

JOINT, SPECIAL (Honda Code 6441620)

15235-HN2-000

$5.75

19

SCREEN, OIL FILTER

15421-HL4-000

$11.84

20

NECK, OIL FILLER

15622-HL6-A00

$1.97

21

TUBE, FILLER NECK

15623-HL6-A00

$10.10

22

CAP, OIL TANK

15651-HN2-000

$5.81

23

CLAMP, HOSE (22-29MM)

19517-ML7-691

$11.62

24

BOLT, FLANGE (6MM)

90111-162-000

$2.89

25

PIN, DOWEL (8X50)

90701-HN2-000

$6.75

26

BEARING, RADIAL BALL (6304)

91001-GF6-004

$20.45

27

BEARING, RADIAL BALL (607ZZ)

91026-MGS-D21

$9.77

28

BEARING, RADIAL BALL (696ZZ)

91027-MGS-D21

$8.69

29

BEARING, NEEDLE (14X20X12)

91028-MGS-D21

$5.39

30

PIN, DOWEL (8X26.4)

91103-KT7-000

$2.80

31

OIL SEAL (12X20X5) (ARAI)

91205-KF0-003

$3.47

32

O-RING (7X1.7)

91301-473-003

$2.72

33

O-RING (11.8X1.9)

91301-KYJ-901

$1.49

34

O-RING (14.8X2.4) (ARAI)

91303-KF0-003

$1.69

35

O-RING (15.8X2.4)

91305-HL6-A00

$2.84

36

O-RING (28X3) (Honda Code 2902443)

91307-MK5-000

$3.67

37

PIN, DOWEL (8X14) (Honda Code 0069310)

94301-08140

$2.25

38

BOLT, FLANGE (6X20) BOLT, SPECIAL FLANGE (6X22)

95701-06020-00

$1.55

39

BOLT, FLANGE (6X28)

95701-06028-00

$1.73

40

BOLT, FLANGE (6X35)

95701-06035-00

$1.80

41

BOLT, FLANGE (6X40) BOLT, FLANGE (6X45)

95701-06040-00
