Yamaha SW396 1970 PRIMARY SHEAVE Diagram

#

Description

Price

1

PRI. SHEAVE CAP (815-17630-00)

8F7-W1762-00-00

Unavailable

2

BOLT

(90109-10080-00)

Unavailable

3

WASHER, LOCK (810-17646-00)

90215-11080-00

Unavailable

4

WASHER, PLATE

90201-10144-00

Unavailable

5

CIRCLIP(4A6)

99009-30400-00

$8.49

6

COLLAR

806-17645-00-00

Unavailable

7

PRI SLIDG SHEAVE

(810-17620-01-00)

Unavailable

8

SPRING, COMPRESSION

90501-45160-00

Unavailable

8

SPRING, COMPRESSION

(90501-45163-00)

Unavailable

9

NUT, BEARING

(810-17642-00-00)

Unavailable

10

WASHER, CONICAL SPR

90208-28003-00

Unavailable

11

SEAT, SPRING

806-17644-00-00

Unavailable

12

BEARING

93306-07806-00

$63.99

13

PRI. FIXED SHEAVE

(810-W1761-00-00)

Unavailable

14

V-BELT

820-17641-01-00

Unavailable
