STEERING GATE
Yamaha SW1NSRLPRB (SIDEWINDER SRX LE EPS) 8PE3 2024 STEERING GATE Diagram
#
1
CROSS TUBE,2
8KC-F1197-00-00
Unavailable
2
CROSS TUBE,1
8KC-F1196-00-00
Unavailable
3
BOLT,FLG. M6X25
8KC-RA153-00-00
$2.02
4
BOLT,FLG. M6X16
8KC-RA146-00-00
$0.70
5
BRACKET 1
8KC-F194X-00-00
$31.99
6
SCREW, 8
8JP-RA297-00-00
$3.08
7
CAP, MAIN PIPE
8JP-F111A-10-00
$3.98
8
NUT, HEX. LOCKING
8JP-RA372-00-00
$0.54
9
BOLT, FLG. M6X1.0X
8JP-RA182-00-00
$0.75
10
WASHER,LOCK-1/4 EXT TOOTH TYP
8JM-RA407-00-00
$0.27
11
NUT,FLG. M6-1.0
8JM-RA322-00-00
$1.07
12
REINF.,FRAME FR. 4
8KC-F1932-00-00
$116.99
13
NUT, HEX. LOCKING
8JP-RA371-00-00
$1.16
14
BRACKET 5
8MT-F112K-00-00
$15.99
15
MEMBER, SIDE 1
8KC-F111J-00-00
$127.99
16
MEMBER, SIDE 2
8JP-F111K-00-00
Unavailable
17
BOLT, FLG. M8X1.25
8JP-RA185-00-00
Unavailable
18
SCREW, 10-12X1.00
8KC-RA288-00-00
Unavailable
19
CLAMP, 21
8JP-RAB23-10-00
Unavailable
20
CLIP
8JP-F11C2-00-00
Unavailable
21
SCREW, 1
8KC-RA235-00-00
Unavailable
22
BOLT, FLANGE M8-1.25X25
8JM-RA102-00-00
Unavailable
23
BOLT, FLANGE
8NS-RA104-00-00
Unavailable
24
GATE, STEERING
8KC-F3871-00-00
Unavailable
25
PIPE, CROSS, 7
8KC-F119E-00-00
Unavailable
26
PIPE CROSS 8
8KC-F119F-00-00
Unavailable
27
BOLT, FLG. M10X1.2
8JP-RA197-00-00
Unavailable
28
SCREW
8KG-RA229-00-00
Unavailable
29
CLAMP, 2
8MT-RAB01-00-00
Unavailable
30
SCREW, 2
8KC-RA236-00-00
Unavailable
