Yamaha SW10RLHL (SIDEWINDER R TX LE) 8LR1 2017 INSTRUMENT PANEL Diagram

#

Description
Price

1

PANEL, INSTRUMENT

8JP-K7712-00-00

Unavailable

2

SCREW, 10-12X3/4

8KC-RA290-00-00

$1.86

3

LOUVER 1

8KC-K7131-00-00

Unavailable

4

SCREW, M6-1.0X18

8JP-RA253-00-00

$1.86

5

PANEL, INSTRUMENT (DEEP PURPLISH BLUE SOLID E)

8KC-K7711-20-00

Unavailable

6

SWITCH (HEATER)

8JP-H2627-00-00

$78.99

7

PLATE, BACK UP 1

8KC-K7153-00-00

Unavailable

8

CLIP, 6

8JP-RAC15-00-00

$9.49

9

WASHER

8JP-RA429-00-00

$1.16

10

SCREW, 13

8JP-RA2A2-00-00

$0.43

11

KNOB

8KC-K7324-00-00

$1.86

12

NUT

8JP-K6169-00-00

Unavailable

13

SCREW, 10-12X3/4

8KC-RA290-00-00

$1.86

14

SCREW, TAPPING 1/4

8JP-RA202-00-00

$1.86
